LM215WF9-SLB1 LG Display 21.5" 1920(RGB)×1080, FHD 102PPI 250 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	LG Display
Model Number :	LM215WF9-SLB1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Delivery Time :	1-2DAYS

Add to Cart

Product Details
Company Profile

LM215WF9-SLB1 LG Display 21.5" 1920(RGB)×1080, FHD 102PPI 250 cd/m² INDUSTRIAL LCD DISPLAY

LG Display LM215WF9-SLB1 Application Details

Basic Information :	Brand		Model	LM215WF9-SLB1
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	21.5"	Alias	LM215WF9 (SL)(B1)
Environment :	Storage Temp.	-20 ~~ 60 °C	Operating Temp.	0 ~~ 50 °C

LG Display LM215WF9-SLB1 Mechanical Details

Pixel Features :	Resolution	1920(RGB)×1080, FHD	Dot Pitch(mm)	0.08265×0.24795 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.24795×0.24795 (H×V) [102PPI]
Mechanical Size :	Active Area(mm)	476.064(H) × 267.786(V)	Bezel Area(mm)	479.3(H) × 271(V)
Mechanical Size :	Outline Dim.(mm)	489.3(H) × 287(V)	Depth(mm)	9.6/13.3 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape	Normal bezel
Outline Features :	Aspect Ratio	16:9 (H:V)	Orientation	Landscape type
Mounting :	Without
Other Spec :	Weight	1.64/1.73Kgs (Typ./Max.)	Treatment	Antiglare (Haze 25%), Hard coating (3H)

LG Display LM215WF9-SLB1 Optical Details

Basic Information :	Luminance(cd/m²)	250 (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	IPS, Normally Black, Transmissive
	Best View on	Symmetry	Response(ms)	14 (Typ.)(G to G)
Color Performance :	White Coordinate	X:0.313; Y:0.329	Display Colors	16.7M (6-bit + Hi-FRC)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamut :	NTSC Ratio	74%	sRGB	94% coverage
	Adobe RGB	73% coverage	DCI-P3	77% coverage
	Rec.2020	55% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM215WF9-SLB1 Interface Details

Signal Electrical :	Voltage Supply	5.0V (Typ.)		Current Supply	600/740mA (Typ./Max.)
Signal Electrical :	Consumption	3.0/3.75W (Typ./Max.)
Signal Type :	LVDS (2 ch, 8-bit)			Signal Voltage	-
Interface Features :	Position			Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	UJU	IS100-L30O-C23	1 pcs	30 pins	1.0 mm	LVDS-30P2C8B-160B

LG Display LM215WF9-SLB1 Backlight Details

Backlight Features:	Shape	4 strings	Type	WLED	Position	Edge light type (Bottom side)
Backlight Features:	Replacement	-	Quantity	14S4P	Life Time	30K(Min.) (Hours)
Lamp Electrical :	Voltage Supply	38.8±2.8V		Current Supply	45/50mA (Typ./Max.)
Lamp Electrical :	Consumption	7.0/7.5W (Typ./Max.)
Interface Features :	Position			Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	JST	BM06B-SHJS-TB(HF)	1 pcs	6 pins	1.0 mm	BLE-6PINS-CCAANC
Backlight Driver :	No

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 476.064(W)×267.786(H) mm, outline size of 489.3(W)×287(H)×13.3(D) mm, viewing area size of 479.3(W)×271(H) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 1.64/1.73Kgs (Typ./Max.). As a IPS, Normally Black, Transmissive LCM product, LM215WF9-SLB1 can provides 250 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted 14S4P WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 30K hours, external backlight driver is additionally needed. LM215WF9-SLB1 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.
