MV238FHM-N20 BOE 23.8" 1920(RGB)×1080, 250 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	BOE
Model Number :	MV238FHM-N20
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Delivery Time :	1-2DAYS

Add to Cart

Product Details
Company Profile

MV238FHM-N20 BOE 23.8" 1920(RGB)×1080, 250 cd/m² INDUSTRIAL LCD DISPLAY

BOE MV238FHM-N20 Application Details

Basic Info :	Panel Brand		Panel Model	MV238FHM-N20
	Diagonal Size	23.8"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

BOE MV238FHM-N20 Mechanical Details

Pixel Features :	Pixel Format	1920(RGB)×1080 [FHD]	Dot Pitch	0.0915×0.2745 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.2745×0.2745 mm (H×V) [92PPI]
Mechanical Size :	Display Area	527.04×296.46 mm (H×V)	Bezel Area	-
Mechanical Size :	Outline Dim.	535×313 mm (H×V)	Outline Depth	8.7/13.2 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Shape Style	3-side borderless
Holes & Brackets :	Rear mounting holes (13-M3)
Other Features :	Weight	2.20Kgs (Typ.)	Surface	Antiglare, Hard coating (3H)

BOE MV238FHM-N20 Optical Details

Basic Information :	Brightness	250 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	ADS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	14 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Color Numbers	16.7M (6-bit + Hi-FRC)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamut :	NTSC Ratio	74%	sRGB	96% coverage
	Adobe RGB	74% coverage	DCI-P3	77% coverage
	Rec.2020	55% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

BOE MV238FHM-N20 Backlight Details

Back-light Features:	Lamp Shape	3 strings	Lamp Type	WLED	Life Time	30K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	3 strings	Position	Edge light type (Bottom side)
Lamp Electrical :	Voltage Input	40/46.4/51.2V (Min./Typ./Max.)		Current Input	58/70mA (Typ./Max.)
Lamp Electrical :	Consumption	10.76/11.88W (Typ./Max.)
Interface Features :	Type	Connector	Position		Lamp Driver	No
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	JST	BM06B-SHJS-TB(HF)	1.0 mm	6 pins	1 pcs	BLE-6PINS-CCAANC

BOE MV238FHM-N20 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	5.0V (Typ.)		Current Input	700/900mA (Typ./Max.)
Signal Electrical :	Consumption	3.5/4.5W (Typ./Max.)
Interface Features :	Type	Connector	Position
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	UJU	IS100-L30R-C23	1.0 mm	30 pins	1 pcs	LVDS-30P2C8B-160A

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 527.04(W)×296.46(H) mm, outline size of 535(W)×313(H)×13.2(D) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 2.20Kgs (Typ.). As a ADS, Normally Black, Transmissive LCM product, MV238FHM-N20 can provides 250 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 74% (NTSC). This product adopted 3 strings WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 30K hours, external backlight driver is additionally needed. MV238FHM-N20 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.).
