PC238CT01-2 HKC 23.8" 1920(RGB)×1080, 0 cd/m² INDUSTRIAL LCD DISPLAY

HKC PC238CT01-2 Application Details

Basic Info :	Panel Brand		Panel Model	PC238CT01-2
	Diagonal Size	23.8"	Application
	Panel Type	a-Si TFT-LCD , CELL	Model Alias	-
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

HKC PC238CT01-2 Mechanical Details

Pixel Features :	Pixel Format	1920(RGB)×1080 [FHD]	Dot Pitch	0.0915×0.2745 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.2745×0.2745 mm (H×V) [92PPI]
Mechanical Size :	Display Area	527.04×296.46 mm (H×V)	Bezel Area	-
Mechanical Size :	Outline Dim.	534.04×307.76 mm (H×V)	Outline Depth	1.31 (Typ.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Plate Thickness	0.50+0.50 mm
Other Features :	Weight	519g (Typ.)	Surface	Antiglare (Haze 25%), Hard coating (3H)

HKC PC238CT01-2 Optical Details

Basic Information :	Brightness	0 cd/m²	Contrast Ratio	3000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	FSA, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	9.5 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.310; Wy:0.301	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	6974K	White Uniformity	-
1931 Color Gamut :	NTSC Ratio	72%	sRGB	96% coverage
	Adobe RGB	73% coverage	DCI-P3	74% coverage
	Rec.2020	53% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :	Outdoor Visibility	No	Transmittance	5.0% (Typ.)

HKC PC238CT01-2 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	5.0V (Typ.)		Current Input	1.0/1.4A (Typ./Max.)
Signal Electrical :	Consumption	5.0/7.0W (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	STM	MSBKT2407P30HL	1.0 mm	30 pins	1 pcs

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 527.04(W)×296.46(H) mm, outline size of 534.04(W)×307.76(H)×1.31(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 519g (Typ.), utilizing 0.50+0.50 mm mm plate. As a FSA, Normally Black, Transmissive CELL product, PC238CT01-2 can provides 3000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 9.5 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product have no backlight. PC238CT01-2 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.)
