DV320FHM-NN0 BOE 32.0" 1920(RGB)×1080, 400 (Typ.)(cd/m²) INDUSTRIAL LCD DISPLAY

BOE DV320FHM-NN0 Application Details

Basic Detail :	Manufacturer		Model Name	DV320FHM-NN0
	Panel Type	a-Si TFT-LCD , LCM	Another Name	-
	Panel Size	32.0 inch	Designed For
Maximum Ratings :	OP Temperature	0 ~ 50 °C	ST Temperature	-20 ~ 60 °C

BOE DV320FHM-NN0 Optical Details

Basic Information :	Luminance	400 cd/m² (Typ.)	Contrast Ratio	1200 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	8 (Typ.)(G to G) (ms)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Operating Mode	ADSDS, Normally Black, Transmissive
Color Performance :	Chromaticity	Wx:0.280; Wy:0.290	Support Color	16.7M (8-bit)
Color Performance :	Color Temperature	9969K	White Uniformity	1.38 (Max.)(9 points)
1931 Color Gamut :	NTSC Ratio	76%	sRGB	97% coverage
	Adobe RGB	76% coverage	DCI-P3	78% coverage
	Rec.2020	57% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

BOE DV320FHM-NN0 Mechanical Details

Pixel Features :	Number of Pixel	1920(RGB)×1080 [FHD]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.12125×0.36375 mm	Pixel Pitch(W×H)	0.36375×0.36375 mm [69PPI]
Physical Size :	Active Viewing	698.4(W)×392.85(H) mm	Overall Dim.	716.2(W)×415.05(H) mm
Physical Size :	Bezel Opening	-	Overall Depth	8.95 (Typ.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape / Portrait
Outline Features :	Aspect Ratio(W:H)	16:9	Shape Style
Other Detail :	Mass	4.00Kgs (Typ.)	Surface	Antiglare (Haze 1%)

BOE DV320FHM-NN0 Interface Details

Signal Electrical :	Input Current	333/630mA (Typ./Max.)		Input Voltage	12.0V (Typ.)
Signal Electrical :	Consumption	4.0/7.6W (Typ./Max.)	Signal Interface	LVDS (2 ch, 8-bit)
Interface Features :	Position	-	Physical Type	Connector
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :	UJU	IS050-C51B-C39-S	1 pcs	0.5 mm	51 pins

BOE DV320FHM-NN0 Lightting Details

Lamp Features:	Lamp Shape	-	Lamp Type	WLED	Position	Edge light type
Lamp Features:	Exchange	-	Amount	-	Life	30K(Min.) (Hours)
Interface Features :	Position	-	Physical Type	Connector
Interface Detail :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Interface Detail :			1 pcs	2.0 mm	14 pins
Backlight Driver :	With LED Driver
Driver Electrical :	Input Current	0.7/2.0A (Typ./Max.)		Input Voltage	24.0V (Typ.)
Driver Electrical :	Consumption	36/63.75W (Typ./Max.)

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 698.4(W)×392.85(H) mm, outline size of 716.2(W)×415.05(H) mm, with surface treament of Antiglare (Haze 1%), net weight of 4.00Kgs (Typ.). As a ADSDS, Normally Black, Transmissive LCM product, DV320FHM-NN0 can provides 400 cd/m² display brightness 1200:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 30K hours, With LED Driver. DV320FHM-NN0 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.).
