DV490FHM-NV0 BOE 49" 1920(RGB)×1080, 500 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	BOE
Model Number :	DV490FHM-NV0
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Delivery Time :	1-2DAYS

Add to Cart

Product Details
Company Profile

DV490FHM-NV0 BOE 49" 1920(RGB)×1080, 500 cd/m² INDUSTRIAL LCD DISPLAY

BOE DV490FHM-NV0 Application Details

Basic Info :	Panel Brand		Panel Model	DV490FHM-NV0
	Diagonal Size	49"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

BOE DV490FHM-NV0 Mechanical Details

Pixel Features :	Pixel Format	1920(RGB)×1080 [FHD]	Dot Pitch	0.1865×0.5595 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.5595×0.5595 mm (H×V) [45PPI]
Mechanical Size :	Display Area	1074.24×604.26 mm (H×V)	Bezel Area	1074.54×604.56 mm (H×V)
Mechanical Size :	Outline Dim.	1078.34×608.36 mm (H×V)	Outline Depth	40.2/59.67 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Shape Style
Holes & Brackets :	Rear mounting holes
Videowall Seam :	4.1 mm (Active to Active)
Other Features :	Weight	18.0Kgs (Typ.)	Surface	Antiglare (Haze 25%), Hard coating (3H)

BOE DV490FHM-NV0 Optical Details

Basic Information :	Brightness	500 cd/m² (Typ.)	Contrast Ratio	-
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	ADS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	8 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.280; Wy:0.290	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	9969K	White Uniformity	1.33 (Max.)(5 points)
1931 Color Gamut :	NTSC Ratio	77%	sRGB	98% coverage
	Adobe RGB	79% coverage	DCI-P3	80% coverage
	Rec.2020	58% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

BOE DV490FHM-NV0 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	30K(Typ.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Direct light type
Interface Features :	Type	Connector	Position	-	Lamp Driver	With LED Driver
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	CviLux	CI0114M1HR0-NH	2.0 mm	14 pins	1 pcs
Driver Electrical :	Voltage Input	24.0±2.4V		Current Input	6.5/7.2A (Typ./Max.)
Driver Electrical :	Consumption	140/155W (Typ./Max.)

BOE DV490FHM-NV0 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	12.0V (Typ.)		Current Input	560/950mA (Typ./Max.)
Signal Electrical :	Consumption	6.8/11.4W (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	UJU	IS050-C51B-C39-S	0.5 mm	51 pins	1 pcs

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1074.24(W)×604.26(H) mm, outline size of 1078.34(W)×608.36(H)×59.67(D) mm, viewing area size of 1074.54(W)×604.56(H) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 18.0Kgs (Typ.), active_to_active splicing seam 4.1 mm. As a ADS, Normally Black, Transmissive LCM product, DV490FHM-NV0 can provides 500 cd/m² display brightness, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Direct light type and have a working life time of 30K hours, With LED Driver. DV490FHM-NV0 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.)
