EV220WPB-N10 BOE 22.0" 1680(RGB)×1050, 350 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	BOE
Model Number :	EV220WPB-N10
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/WESTERN UNION/ESCROWS
Delivery Time :	1-2DAYS

Add to Cart

Product Details
Company Profile

EV220WPB-N10 BOE 22.0" 1680(RGB)×1050, 350 cd/m² INDUSTRIAL LCD DISPLAY

BOE EV220WPM-N10 Application Details

Basic Info :	Panel Brand		Panel Model	EV220WPM-N10
	Diagonal Size	22.0"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	0 ~ 60 °C	Storage Temp.	-20 ~ 60 °C

BOE EV220WPM-N10 Mechanical Details

Pixel Features :	Pixel Format	1680(RGB)×1050 [WSXGA+]	Dot Pitch	0.094×0.282 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.282×0.282 mm (H×V) [90PPI]
Mechanical Size :	Display Area	473.76×296.1 mm (H×V)	Bezel Area	477.7×300.1 mm (H×V)
Mechanical Size :	Outline Dim.	493.7×320.1 mm (H×V)	Outline Depth	10.9/16.35 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:10 (H:V)	Shape Style
Holes & Brackets :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Weight	TBD	Surface	Antiglare (Haze 25%)

BOE EV220WPM-N10 Optical Details

Basic Information :	Brightness	350 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	HADS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	25 (Typ.)(Tr+Td) (ms)
Color Performance :	Chromaticity	Wx:0.307; Wy:0.326	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	6846K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamut :	NTSC Ratio	77%	sRGB	100% coverage
	Adobe RGB	80% coverage	DCI-P3	80% coverage
	Rec.2020	58% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

BOE EV220WPM-N10 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	30K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Edge light type
Interface Features :	Type	Connector	Position	-	Lamp Driver	With LED Driver
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	STM	MS24049HJ	1.25 mm	9 pins	1 pcs
Driver Electrical :	Voltage Input	8/12/21V (Min./Typ./Max.)		Current Input	1.47A (Typ.)
Driver Electrical :	Consumption	17.68W (Typ.)

BOE EV220WPM-N10 Interface Details

Signal Systerm :	LVDS (2 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	5.0V (Typ.)		Current Input	TBD
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	UJU	IS100-L30O-C23	1.0 mm	30 pins	1 pcs	LVDS-30P2C8B-160A

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 473.76(W)×296.1(H) mm, outline size of 493.7(W)×320.1(H)×16.35(D) mm, viewing area size of 477.7(W)×300.1(H) mm, with surface treament of Antiglare (Haze 25%), net weight of TBD. As a HADS, Normally Black, Transmissive LCM product, EV220WPM-N10 can provides 350 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 73% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 30K hours, With LED Driver. EV220WPM-N10 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.).
