19.0" 1440x900 Industrial TFT Display 250cd/m2 89PPI LM190WX2-TLB1

Ask Lasest Price
Brand Name :	LG DISPLAY
Model Number :	LM190WX2-TLB1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	350PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

19.0" 1440x900 Industrial TFT Display 250cd/m2 89PPI LM190WX2-TLB1

LG Display LM190WX2-TLB1 Application Details

Basic Detail :	Manufacturer LM190WX2-TLB1Model Name Panel Type a-Si TFT-LCD , LCM Another Name LM190WX2 (TL)(B1) Panel Size 19.0 inch Designed For
Maximum Ratings :	OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C

LG Display LM190WX2-TLB1 Optical Details

Basic Detail :	Luminance 250 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive) Good View at 6 o'clock Response Speed 1.3/3.7 (Typ.)(Tr/Td) ms Viewing Angle 85/85/80/80 (Typ.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance :	Chromaticity Wx:0.313; Wy:0.329 Support Color 16.7M (8-bit) Color Temperature 6485K White Variation 1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 72% sRGB 97% coverage Adobe RGB 75% coverage DCI-P3 75% coverage Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM190WX2-TLB1 Mechanical Details

Pixel Features :	Number of Pixel 1440(RGB)×900, WXGA+ Arrangement RGB Vertical Stripe Dot Pitch(W×H) 0.0945×0.2835 mm Pixel Pitch(W×H) 0.2835×0.2835 mm [89PPI]
Physical Size :	Active Viewing 408.24(W)×255.15(H) mm Overall Dim. 428(W)×278(H) mm Bezel Opening 412.2(W)×259.0(H) mm Overall Depth 8.6/10.7 (Typ./Max.) mm
Outline Features :	Form Shape Flat Rectangle Orientation Landscape type Aspect Ratio(W:H) 16:10 Shape Style Normal bezel
Fixation :	Side mounting holes (4-M3) on left, right bezel
Other Detail :	Mass 1.40Kgs (Typ.) Surface Antiglare, Hard coating (3H)

LG Display LM190WX2-TLB1 Interface Detail

Signal Electrical :	Input Current 970±150mA Input Voltage 5.0V (Typ.) Consumption 4.2/4.85W (Typ./Max.) Signal Interface LVDS (2 ch, 8-bit)
Interface Features :	Position ConnectorType
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment LS Mtron GT103-30S-HF15-E2500 1.0 mm 30 pins 1 pcs LVDS-30P2C8B-160C

LG Display LM190WX2-TLB1 Lightting Details

Lamp Features :	Lamp Type WLED Amount 13S2P Position Edge light type (Right side) Exchange - Lamp Shape 2 strings Lamp Life 30K(Min.) (Hours)
Lamp Electrical :	Input Voltage 39.0±2.6V Input Current 75/80mA (Typ./Max.) Consumption 5.9/46.2W (Typ./Max.)
Interface Features :	Position ConnectorType
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment JST SM06B-SHJH(HF) 1.0 mm 6 pins 1 pcs BLE-6PINS-CNAANC

LG Display LM190WX2-TLB1 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	12 pcs / box	-	350×300×470 mm

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
