13.3" 3200×1800 Industrial TFT Display 226PPI 300cd/M2 LP133QD1-SPA1

Ask Lasest Price
Brand Name :	LG DISPLAY
Model Number :	LP133QD1-SPA1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	350PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

13.3" 3200×1800 Industrial TFT Display 226PPI 300cd/M2 LP133QD1-SPA1

LG Display LP133QD1-SPA1 Application Features

Basic Information :	Brand	Model	Type	Model Alias
Basic Information :		LP133QD1-SPA1	a-Si TFT-LCD , LCM	LP133QD1 (SP)(A1), LGD04B4
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LP133QD1-SPA1 Mechanical Features

Panel Size :	13.3 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	3200(WR/GB)×1800	RG/BW LCD PenTile	0.04584×0.09168 mm	0.09168×0.09168 mm [226PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	293.38×165.02 mm	296.5×168.15 mm	306.15×188.2 mm	2.6/2.9 (Typ./Max.) mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9 (W : H)	Landscape type	Slim (PCBA Flat, T≤3.2mm)
Fixation :	Without
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	210g (Max.)	Glare (Haze 0%)

LG Display LP133QD1-SPA1 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	300 cd/m² (Typ.)	IPS, Normally Black, Transmissive	400:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	85/85/85/85 (Typ.)(CR≥10)	Symmetry	25 (Typ.)(Tr+Td) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	6485K	16.7M (8-bit)	X:0.313; Y:0.329
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	76%	98%	76%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	78%	56%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :	1.40/1.60 (Max.)(5/13 points)

LG Display LP133QD1-SPA1 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	420/486mA (Typ./Max.)		3.3V (Typ.)			1.40/1.60W (Typ./Max.)
Interface Features :	Position	Type	Interface
Interface Features :		Connector	eDP (4 Lanes)
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Signal Interface :	JAE	HD1S040HA2	1 pcs	0.5 mm	40 pins

LG Display LP133QD1-SPA1 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	-	-	15K(Min.)	-
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Included in panel signal interface	With LED Driver
Driver Electrical :	Current Input		Voltage Input			Consumption
Driver Electrical :	443/453mA (Typ./Max.)		6.0/12.0/21.0V (Min./Typ./Max.)			5.33/5.44W (Typ./Max.)

LG Display LP133QD1-SPA1 Packing Features

Package Carton :	Amount	Weight	Carton Size
Package Carton :	20 pcs / box	-	478×365×288 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
