19.0" 1280x1024 700cd/m2 Industrial TFT Display 86PPI LB190E02-SL04

Ask Lasest Price
Brand Name :	LG DISPLAY
Model Number :	LB190E02-SL04
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	350PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

19.0" 1280x1024 700cd/m2 Industrial TFT Display 86PPI LB190E02-SL04

LG Display LB190E02-SL04 Application Features

Basic Information :	Manufacturer	Panel Model	Panel Type	Alias
Basic Information :		LB190E02-SL04	a-Si TFT-LCD , LCM	LB190E02 (SL)(04)
Environment :	RoHS State	Operating Temp.	Storage Temp.	Vibration Level
Environment :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LB190E02-SL04 Optical Features

Basic Information :	Luminance (cd/m²)	Viewing Angle (L/R/U/D)	Response Time (ms)
	700 (Typ.)	89/89/89/89 (Typ.)(CR≥10)	14 (Typ.)(G to G)
	Best View on	Display Mode	Contrast Ratio
	Symmetry	IPS, Normally Black, Transmissive	900 : 1 (Typ.) (Transmissive)
Dispaly Color :	Color Temperature	Display Colors	White Coordinate
Dispaly Color :	9085K	16.7M (8-bit)	X:0.280; Y:0.310
White Variation :	1.33 (Max.)(9 points)
Performance :	3D Tech	Sunlight Visibility	Reflectance
Performance :	-	Sunlight Readable

LG Display LB190E02-SL04 Mechanical Features

Panel Size :	19.0"
Pixel Features :	Pixel Format	Pixel Configuration	Pixel Pitch (mm)	Dot Pitch (mm)
Pixel Features :	1280(RGB)×1024 [SXGA]	RGB Vertical Stripe	0.294×0.294 [86PPI]	0.098×0.294
Mechanical Size :	Active Area (mm)	Bezel Area (mm)	Outline Dimension (mm)	Outline Depth (mm)
Mechanical Size :	376.32(H) × 301.056(V)	380.3(H) × 305.0(V)	400(H) × 330(V)	13.8±0.5 mm
Outline Features :	Form Factor	Orientation	Aspect Ratio	Shape Style
Outline Features :	Flat Rectangle	Landscape type	5:4 (H:V)
Mounting :	Side mounting holes (4-M3) on left, right bezel
Other Detail :	Weight	Panel Cover	Treatment
Other Detail :	1.55/1.60Kgs (Typ./Max.)	-	Antiglare, Hard coating (3H)

LG Display LB190E02-SL04 Backlight Features

Lamp Features:	Type	Position	Quantity	Shape	Life(Hours)	Lamp Exchange
Lamp Features:	WLED	Edge light type (Bottom side)	4 strings	4 strings	50K(Min.)	-
WLED Electrical :	Voltage Supply		Current Supply			Power
WLED Electrical :	38.4/40.8V (Typ./Max.)		130mA (Typ.)			20.0/21.2W (Typ./Max.)
Interface Features :	Position	Backlight Driver				Type
Interface Features :		No				Connector
Interface Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Interface Detail :	YEONHO	05010HR-06C(G)	0.5 mm	6 pins	1 pcs	BLE-6PINS-CCAACC

LG Display LB190E02-SL04 Interface Features

Panel Driving Electrical :	Voltage Supply		Current Supply			Power
Panel Driving Electrical :	5.0V (Typ.)		0.80/1.04A (Typ./Max.)			4.0/5.2W (Typ./Max.)
Interface Features :	Position	Signal				Type
Interface Features :		LVDS (2 ch, 8-bit)				Connector
Connector Detail :	Brand	Model	Pin Pitch	Pin Amount	Quantity	Configuration
Connector Detail :	LS Mtron	GT103-30S-H23	1.0 mm	30 pins	1 pcs	LVDS-30P2C8B-160A

LG Display LB190E02-SL04 Packing Features

Package Box :	Quantity	Weight	Box Size
Package Box :	12 pcs / box	-	408×355×474 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
