LG Display 26.0" 60PPI1366x768 TFT LCD Panel 350cd/m2 LC260EXN-SDA1

Ask Lasest Price
Brand Name :	LG DISPLAY
Model Number :	LC260EXN-SDA1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	600PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

LG Display 26.0" 60PPI1366x768 TFT LCD Panel 350cd/m2 LC260EXN-SDA1

LG Display LC260EXN-SDA1 Application Features

Basic Information :	Brand	Model	Type	Model Alias
Basic Information :		LC260EXN-SDA1	a-Si TFT-LCD , LCM	LC260EXN (SD)(A1)
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :		0 ~ 50 °C	-20 ~ 60 °C

LG Display LC260EXN-SDA1 Mechanical Features

Panel Size :	26.0 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	1366(RGB)×768, WXGA	RGB Vertical Stripe	0.1405×0.4215 mm	0.4215×0.4215 mm [60PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	575.769×323.712 mm	580.2×328.2 mm	609.8×357.8 mm	10.0/18.5 (Typ./Max.) mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9 (W : H)	Landscape type
Fixation :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	2.58/2.70Kgs (Typ./Max.)	Antiglare, Hard coating (3H)

LG Display LC260EXN-SDA1 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	350 cd/m² (Typ.)	S-IPS, Normally Black, Transmissive	1000:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	89/89/89/89 (Min.)(CR≥10)	Symmetry	6 (Typ.)(G to G) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	9972K	16.7M (6-bit + Hi-FRC)	X:0.279; Y:0.292
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	69%	93%	71%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	72%	52%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :	1.30 (Max.)(5 points)

LG Display LC260EXN-SDA1 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	225/293mA (Typ./Max.)		12.0V (Typ.)			2.7/3.51W (Typ./Max.)
Interface Features :	Position	Type	Interface
Interface Features :	-	Connector	LVDS (1 ch, 8-bit)
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Signal Interface :	HRS	KDF71G-30S-1H	1 pcs	1.0 mm	30 pins	LVDS-30P1C8B-015C

LG Display LC260EXN-SDA1 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	-	-	30K(Min.)	-
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Connector	With LED Driver
Interface Detail	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Interface Detail	JST	SM14B-SRSS-TB	1 pcs	1.0 mm	14 pins
Driver Electrical :	Current Input		Voltage Input			Consumption
Driver Electrical :	1.10/1.17A (Typ./Max.)		24.0±1.2V			26.5/28.1W (Typ./Max.)

LG Display LC260EXN-SDA1 Packing Features

Package Carton :	Amount	Weight	Carton Size
Package Carton :	9 pcs / box	-	710×365×447 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
