    55" 80PPI 3840×2160 WLED TFT Display 500cd/m2 LD550EQE-FKA1 89/89/89/89 (Typ.)(CR≥10)

    Ask Lasest Price
    Brand Name : LG DISPLAY
    Model Number : LD550EQE-FKA1
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 600PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    55" 80PPI 3840×2160 WLED TFT Display 500cd/m2 LD550EQE-FKA1 89/89/89/89 (Typ.)(CR≥10)

    LG Display LD550EQE-FKA1 Application Features

    Basic Information :BrandModelTypeModel Alias
    LD550EQE-FKA1a-Si TFT-LCD , LCMLD550EQE (FK)(A1)
    Reliability :RoHSOperating TemperatureStorage TemperatureVibration Resistance
    0 ~ 50 °C-20 ~ 60 °C

    LG Display LD550EQE-FKA1 Mechanical Features

    Panel Size :55 inch
    Pixel Features :ResolutionPixel ArrangementDot Pitch (W×H)Pixel Pitch (W×H)
    3840(RGB)×2160, UHDRGB Vertical Stripe0.105×0.315 mm0.315×0.315 mm [80PPI]
    Mechanical Size :Active Area (W×H)Bezel Area (W×H)Outline Dimension (W×H)Outline Depth
    1209.6×680.4 mm1214.6×685.4 mm1233.4×706.8 mm29.9 (Max.) mm
    Outline Features :Form StyleAspect RatioOrientationShape Style
    Flat Rectangle16:9 (W : H)Landscape / Portrait
    Other Features :Panel CoverWeightSurface
    -13.9/14.4Kgs (Typ./Max.)Antiglare (Haze 28%), Hard coating (2H)

    LG Display LD550EQE-FKA1 Optical Features

    Basic Information :BrightnessOperating ModeContrast Ratio
    500 cd/m² (Typ.)IPS, Normally Black, Transmissive1100:1 (Typ.) (Transmissive)
    Viewing Angle(L/R/U/D)Viewing DirectionResponse Speed
    89/89/89/89 (Min.)(CR≥10)Symmetry8 (Typ.)(G to G) (ms)
    Dispaly Color :Color TemperatureColor AmountWhite color Chromaticity
    9972K1.07B (8-bit + Dithering)X:0.279; Y:0.292
    1931 Color Gamlt :NTSC RatiosRGB CoverageAdobe RGB Coverage
    70%94%72%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    73%52%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    Luminance Variation :1.54 (Max.)(9 points)

    LG Display LD550EQE-FKA1 Interface Features

    Signal Electrical :Current InputVoltage InputConsumption
    1.2/1.56A (Typ./Max.)12.0V (Typ.)14.2/18.75W (Typ./Max.)
    Interface Features :PositionTypeInterface
    -ConnectorV-by-One 8 lane
    Signal Interface :BrandModelAmountPin PitchPinsPin Assignment
    JAEFI-RE51S-HF1 pcs0.5 mm51 pins

    LG Display LD550EQE-FKA1 Backlight Features

    Backlight Features:TypePositionShapeAmountLife(Hours)Replacement
    WLEDEdge light type--50K(Typ.)-
    WLED Electrical :Current InputVoltage InputConsumption
    95mA (Typ.)147.6±5V84.1W (Typ.)
    Interface Features :PositionTypeWLED Driver
    -ConnectorNo
    Interface DetailBrandModelAmountPin PitchPinsPin Assignment
    UJUHS100-L08N-N621 pcs1.0 mm8 pinsBLE-8PINS-CCCNNNNA
    UJUHS100-L08N-N62-A1 pcs1.0 mm8 pinsBLE-8PINS-ANNNNCCC

    LG Display LD550EQE-FKA1 Packing Features

    Package Carton :AmountWeightCarton Size
    22 pcs / box-1700×1140×1090 mm (L×W×H)

      FAQ:
      Q1: What's the quality of your LCD Panel?
      A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
      Q2: What is your return and refund policy?
      A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
      Q3: How long is the lead time?
      A: The lead time is about 1-3 working days after receipt of payment.
      Q4: How can I get the quotation?
      A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
