LG Display 23.8" 92PPI 250cd/m2 WLED Tft Display LM238WF4-SSB1

Ask Lasest Price
Brand Name :	LG DISPLAY
Model Number :	LM238WF4-SSB1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	600PCS
Delivery Time :	1-2 DAYS
Price :	120USD

Add to Cart

Product Details
Company Profile

LG Display 23.8" 92PPI 250cd/m2 WLED Tft Display LM238WF4-SSB1

LG Display LM238WF4-SSB1 Application Details

Basic Information :	Brand		Model	LM238WF4-SSB1
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	23.8"	Alias	LM238WF4 (SS)(B1)
Environment :	Storage Temp.	-20 ~~ 60 °C	Operating Temp.	0 ~~ 50 °C

LG Display LM238WF4-SSB1 Mechanical Details

Pixel Features :	Resolution	1920(RGB)×1080, FHD	Dot Pitch(mm)	0.0915×0.2745 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.2745×0.2745 (H×V) [92PPI]
Mechanical Size :	Active Area(mm)	527.04(H) × 296.46(V)	Bezel Area(mm)	-
Mechanical Size :	Outline Dim.(mm)	534.9(H) × 306.95(V)	Depth(mm)	8.9/12.9 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape	4-side borderless
Outline Features :	Aspect Ratio	16:9 (H:V)	Orientation	Landscape type
Mounting :	Rear mounting holes (16-M3)
Other Spec :	Weight	2.00/2.10Kgs (Typ./Max.)	Treatment	Antiglare, Hard coating (3H)

LG Display LM238WF4-SSB1 Optical Details

Basic Information :	Luminance(cd/m²)	250 (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Display Mode	IPS, Normally Black, Transmissive
	Best View on	Symmetry	Response(ms)	14 (Typ.)(G to G)
Color Performance :	White Coordinate	X:0.313; Y:0.329	Display Colors	16.7M (6-bit + Hi-FRC)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	76%	sRGB	100% coverage
	Adobe RGB	77% coverage	DCI-P3	79% coverage
	Rec.2020	57% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM238WF4-SSB1 Interface Details

Signal Electrical :	Voltage Supply	5.0V (Typ.)		Current Supply	0.41/0.51A (Typ./Max.)
Signal Electrical :	Consumption	2.1/2.55W (Typ./Max.)
Signal Type :	LVDS (2 ch, 8-bit)			Signal Voltage	-
Interface Features :	Position			Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	UJU	IS100-L30O-C23	1 pcs	30 pins	1.0 mm	LVDS-30P2C8B-160B

LG Display LM238WF4-SSB1 Backlight Details

Backlight Features:	Shape	4 strings	Type	WLED	Position	Edge light type (Bottom side)
Backlight Features:	Replacement	-	Quantity	14S4P	Life Time	30K(Min.) (Hours)
Lamp Electrical :	Voltage Supply	39±2.8V		Current Supply	60/65mA (Typ./Max.)
Lamp Electrical :	Consumption	9.4/10.1W (Typ./Max.)
Interface Features :	Position			Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :	JST	BM06B-SHJS-TB(HF)	1 pcs	6 pins	1.0 mm	BLE-6PINS-CCAACC
Backlight Driver :	No

LG Display LM238WF4-SSB1 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	10 pcs / box	-	635×370×400 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
