320cd/m² TM057KBHG01 5.7 Inch 320*240 Tianma TFT 70/70/60/70 (Typ.)(CR≥10)

1. Main Information:

The TM057KBHG01 is a 5.7 inch diagonal a-Si TFT-LCD display panel product from Tianma Microelectronics Co., Ltd. with an integral WLED backlight system, without backlight driver, touchscreen 4-wire Resistive Touch. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are following: With Touch, WLED Backlight, Life ≥ 50K hours, U/D,L/R Reverse, Matte . Based on its features,this model be applied to Industrial etc.

2. TIANMA TM057KBHG01 Optical Details:

Basic Information :	Luminance	320 cd/m² (Typ.)	Contrast Ratio	500 : 1 (Typ.) (Transmissive)
	Good View at	6 o'clock	Response Speed	20 (Typ.)(Tr+Td) (ms)
	Viewing Angle	70/70/60/70 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Color Performance :	Chromaticity	Wx:0.320; Wy:0.360	Support Color	262K (6-bit)
Color Performance :	Color Temperature	5983K	White Uniformity	1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	53%	sRGB	73% coverage
	Adobe RGB	56% coverage	DCI-P3	55% coverage
	Rec.2020	40% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

3. TIANMA TM057KBHG01 Mechanical Details:

Pixel Features :	Number of Pixel	320(RGB)×240 [QVGA]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.120×0.360 mm	Pixel Pitch(W×H)	0.360×0.360 mm [70PPI]
Physical Size :	Active Viewing	115.2(W)×86.4(H) mm	Overall Dim.	144(W)×104.6(H) mm
Physical Size :	Bezel Opening	117.6(W)×88.8(H) mm	Overall Depth	14.0 (Max.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio(W:H)	4:3	Shape Style	-
Touchscreen :	TP Controller	Without touch controller	TP Interface	-
Touchscreen :	Touch Points	-	TP Technology	4-wire Resistive Touch
Fixation :	Rear mounting poles (4-Φ2.6)
Other Detail :	Mass	TBD	Surface	Antiglare, Hard coating (3H)

4. TIANMA TM057KBHG01 Lightting Details:

Lamp Features:	Lamp Shape	3 strings	Lamp Type	WLED	Position	Edge light type
Lamp Features:	Exchange	-	Amount	5S3P	Life	50K(Typ.) (Hours)
Lamp Electrical :	Input Current	25mA (Typ.)		Input Voltage	14.85/18.15V (Min./Max.)
Lamp Electrical :	Consumption	1.238mW (Typ.)
Interface Features :	Position	-	Physical Type	Included in panel signal interface
Backlight Driver :	No
