LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers

    Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers
    • Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers
    • Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers
    • Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers
    • Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers
    • Buy cheap LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display from wholesalers

    LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display

    Ask Lasest Price
    Brand Name : LG
    Model Number : LM290WW1-SSA1
    Certification : ISO9001
    Price : 80USD
    Payment Terms : T/T IN ADVANCE, WESTERN UNION, PAYPAL, ESCROW
    Supply Ability : 1000
    Delivery Time : 3 DAY
    • Product Details
    • Company Profile

    LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display

    LG Display LM290WW1-SSA1 Application Details

    LG Display LM290WW1-SSA1 Optical Details

    Basic Information :Luminance300 cd/m² (Typ.)Contrast Ratio1000 : 1 (Typ.) (Transmissive)
    Good View atSymmetryResponse Speed14 (Typ.)(G to G) (ms)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10) LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT DisplayOperating ModeIPS, Normally Black, Transmissive
    Color Performance :ChromaticityWx:0.313; Wy:0.329Support Color16.7M (8-bit)
    Color Temperature6485KWhite Uniformity1.33 (Max.)(9 points) LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    1931 Color Gamlt :NTSC Ratio77%sRGB100% coverage
    Adobe RGB78% coverageDCI-P380% coverage
    Rec.202057% coverageRemarks

    sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)


    Basic Detail :ManufacturerLM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT DisplayModel NameLM290WW1-SSA1
    Panel Typea-Si TFT-LCD , LCMAnother NameLM290WW1 (SS)(A1)
    Panel Size29.0 inchDesigned For
    • LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    Maximum Ratings :OP Temperature0 ~ 50 °CST Temperature-20 ~ 60 °C
    Vibration Level-RoHSLM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    Features :
    • sRGB
    • 3-side boderless
    • WLED Backlight
    • Reverse I/F
    • Matte
    Remarks :

    3-side Borderless, for LG monitor 29UM65



    LG Display LM290WW1-SSA1 Mechanical Details

    Pixel Features :Number of Pixel2560(RGB)×1080 [CSHD]ArrangementRGB Vertical Stripe
    Dot Pitch(W×H)0.0876×0.2628 mmPixel Pitch(W×H)0.2628×0.2628 mm [96PPI]
    Physical Size :Active Viewing672.768(W)×283.824(H) mmOverall Dim.693.6(W)×308.9(H) mm
    Bezel Opening-Overall Depth11.0/17.5 (Typ./Max.) mm
    Outline Features :Form ShapeFlat RectangleOrientationLandscape type
    Aspect Ratio(W:H)21:9Shape Style3-side borderless
    Fixation :Rear mounting poles (13-M2.5)
    Other Detail :Mass3.40/3.57Kgs (Typ./Max.)Surface

    Antiglare, Hard coating (3H)


    LG Display LM290WW1-SSA1 Electronics Details

    Refresh Rate :60Hz LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    Reverse Scan :No
    Power Consumption :31.7W (Typ.)

    LG Display LM290WW1-SSA1 Interface Details

    Signal Electrical :Input Current500±125mAInput Voltage12.0V (Typ.)
    Consumption6.0/7.5W (Typ./Max.)Signal InterfaceLVDS (4 ch, 8-bit)
    Interface Features :PositionDown left of panelPhysical TypeConnector
    Signal Interface :BrandModelAmountPin PitchPin AmountPin Assignment LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    LS MtronGT05P-51S-H38-E15001 pcs0.5 mm51 pins
    LS MtronGT05P-41S-H38-E15001 pcs0.5 mm41 pins

    LG Display LM290WW1-SSA1 Lightting Details

    Lamp Features:Lamp Shape4 stringsLamp TypeWLEDPositionEdge light type (Bottom side)
    Exchange-Amount17S4PLife30K(Min.) (Hours)
    Lamp Electrical :Input Current120/125mA (Typ./Max.)Input Voltage53.6±3.4V
    Consumption25.7/27.3W (Typ./Max.) LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    Interface Features :PositionDown left cornerPhysical TypeConnector
    Interface Detail :BrandModelAmountPin PitchPin AmountPin Assignment LM290WW1-SSA1 29.0 Inch 2560×1080 Viewing Angle89/89/89/89 300cd/M2 LG TFT Display
    JSTSM06B-SHJH(HF)1 pcs1.0 mm6 pinsBLE-6PINS-CCAACC
