    8.1 INCH 800×300RGB 300CD/M2 WLED TTL AUO TFT Display G081VTN01.0

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G081VTN01.0
    Certification : ISO9001
    Price :
    Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROW
    Supply Ability : 100PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    8.1 INCH 800×300RGB 300CD/M2 WLED TTL AUO TFT Display G081VTN01.0

    AUO G081VTN01.0 Application Details

    Basic Detail :ManufacturerModel NameG081VTN01.0
    Panel Typea-Si TFT-LCD , LCMAnother Name-
    Panel Size8.1 inchDesigned For
    Maximum Ratings :OP Temperature0 ~ 60 °CST Temperature-
    Vibration Level-RoHS

    AUO G081VTN01.0 Optical Details

    Basic Information :Luminance300 cd/m² (Min.)Contrast Ratio300 : 1 (Typ.) (Transmissive)
    Good View at-Response Speed10/20 (Typ.)(Tr/Td) (ms)
    Viewing Angle60/60/40/60 (Typ.)(CR≥10)Operating ModeTN, Normally White
    Color Performance :Chromaticity-Support Color16.2M (6-bit + FRC)

    AUO G081VTN01.0 Mechanical Details

    Pixel Features :Number of Pixel800(RGB)×300ArrangementRGB Vertical Stripe
    Dot Pitch(W×H)0.080×0.240 mmPixel Pitch(W×H)0.240×0.240 mm [105PPI]
    Physical Size :Active Viewing192(W)×72(H) mmOverall Dim.204.6(W)×86.2(H) mm
    Bezel Opening194(W)×74(H) mmOverall Depth5.6±0.6 mm
    Outline Features :Form ShapeFlat RectangleOrientationLandscape type
    Aspect Ratio(W:H)8:3Shape Style
    Other Detail :Mass225±10gSurfaceAntiglare

    AUO G081VTN01.0 Electronics Details

    Time Controller (T-CON) :Embedded T-CON

    AUO G081VTN01.0 Interface Details

    Signal Electrical :Input Current11/8/0.02/0.2/0.2mA (Typ.)(IDD/AIDD/GICC/IGH/IGL)Input Voltage3.3/11/3.3/15/-7V (Typ.)(VDD/AVDD/GVCC/VGH/VGL)
    Consumption-Signal InterfaceParallel RGB (1 ch, 8-bit)
    Interface Features :Position-Physical TypeFPC
    Signal Interface :BrandModelAmountPin PitchPin AmountPin Assignment
    1 pcs0.5 mm60 pins

    AUO G081VTN01.0 Lightting Details

    Lamp Features:Lamp Shape1 stringLamp TypeWLEDPositionEdge light type
    Exchange-Amount4S1PLife10K(Min.) (Hours)
    Lamp Electrical :Input Current175/180mA (Typ./Max.)Input Voltage13.2/15.2V (Typ./Max.)
    Interface Features :Position-Physical TypeConnector
    Interface Detail :BrandModelAmountPin PitchPin AmountPin Assignment
    JSTPHR-21 pcs2.0 mm2 pinsBLE-2PINS-AC
    Backlight Driver :No

    FAQ:


    Q1: What's the quality of your LCD Panel?


    A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.


    Q2: What is your return and refund policy?


    A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.


    Q3: How long is the lead time?


    A: The lead time is about 1-3 working days after receipt of payment.


    Q4: How can I get the quotation?


    A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
