    G116HAN01.0 AUO 11.6INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G116HAN01.0
    Certification : ISO9001
    Price :
    Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROW
    Supply Ability : 340PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    G116HAN01.0 AUO 11.6INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

    AUO G116HAN01.0 Application Details

    Basic Information :BrandModelG116HAN01.0
    TypeLCM a-Si TFT-LCDUsed For
    Screen Size11.6"Alias-
    Environment :Storage Temp.-20 ~~ 60 °COperating Temp.0 ~~ 50 °C
    RoHSVibration-

    AUO G116HAN01.0 Mechanical Details

    Pixel Features :Resolution1920(RGB)×1080, FHDDot Pitch(mm)0.0445×0.1335 (H×V)
    Pixel FormatRGB Vertical StripePixel Pitch(mm)0.1335×0.1335 (H×V) [190PPI]
    Mechanical Size :Active Area(mm)256.32(H) × 144.18(V)Bezel Area(mm)-
    Outline Dim.(mm)268(H) × 168.5(V)Depth(mm)3.0 (Max.)
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio16:9 (H:V)OrientationLandscape type
    Mounting :Without
    Other Spec :Weight200g (Max.)TreatmentHard coating (3H)

    AUO G116HAN01.0 Optical Details

    Basic Information :Luminance(cd/m²)300 (Typ.)Contrast Ratio800:1 (Typ.) (Transmissive)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10)Display ModeAHVA, Normally Black, Transmissive
    Best View onSymmetryResponse(ms)25 (Typ.)(Tr+Td)
    Color Performance :White CoordinateX:0.313; Y:0.329Display Colors16.7M (8-bit)
    Color Temperature6485KWhite Uniformity1.43 (Max.)(13 points)
    1931 Color Gamlt :NTSC Ratio55%sRGB75% coverage
    Adobe RGB57% coverageDCI-P357% coverage
    Rec.202041% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    AUO G116HAN01.0 Interface Details

    Signal Electrical :Voltage Supply3.3V (Typ.)Current Supply303mA (Typ.)
    Consumption1.0W (Max.)
    Signal Type :eDP (2 Lanes)Signal Voltage-
    Interface Features :PositionRight of BoardTypeConnector
    Interface Detail :BrandModelQuantityPinsPitchPin Configuration
    STMMSAK24025P30M1 pcs30 pins0.5 mmEDP-30P2L-020A

    AUO G116HAN01.0 Backlight Details

    Backlight Features:Shape-TypeWLEDPositionEdge light type
    Replacement-Quantity-Life Time15K(Min.) (Hours)
    Interface Features :Position-TypeIncluded in panel signal interface
    Backlight Driver :With LED Driver
    Driver Electrical :Voltage Supply5.0/12.0/21.0V (Min./Typ./Max.)Current Supply-
    Consumption2.2W (Max.)
