    TX14D10VM1BPA HITACHI 5.7 inch 640(RGB)×480 280 cd/m² ; Storage Temperature: -30 ~ 80 °C INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : HITIACH
    Model Number : TX14D10VM1BPA
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 200PCS
    Delivery Time : 1-3DAYS
    Price :
    • Product Details
    • Company Profile

    TX14D10VM1BPA HITACHI 5.7 inch 640(RGB)×480 280 cd/m² ; Storage Temperature: -30 ~ 80 °C INDUSTRIAL LCD DISPLAY

    HITACHI TX14D10VM1BPA Application Details

    Basic Information :
    Brand
    Model
    TX14D10VM1BPA
    Type
    a-Si TFT-LCD , LCM
    Used For
    Screen Size
    5.7 inch
    Alias
    -
    Environment :
    Storage Temp.
    -30 ~ 80 °C
    Operating Temp.
    -20 ~ 70 °C
    RoHS
    Vibration
    2.0G (19.6 m/s²)
    Typical Features :

    • WLED Backlight
    • With LED Driver
    • U/D,L/R Reverse
    • Matte
    Remarks :
    LTS|LVDS|4wt|AG|LED|WTR, Introduced 3/5/2010

    HITACHI TX14D10VM1BPA Mechanical Details

    Pixel Features :
    Resolution
    640(RGB)×480, VGA
    Dot Pitch(mm)
    0.060×0.180 (H×V)
    Pixel Format
    RGB Vertical Stripe
    Pixel Pitch(mm)
    0.180×0.180 (H×V) [141PPI]
    Mechanical Size :
    Active Area(mm)
    115.2(H) × 86.4(V)
    Bezel Area(mm)
    119.4(H) × 90.6(V)
    Outline Dim.(mm)
    131(H) × 102(V)
    Depth(mm)
    13.1±0.5
    Outline Features :
    Form Style
    Flat Rectangle
    Shape Style
    Aspect Ratio
    4:3 (H:V)
    Orientation
    Landscape type
    Touch Panel :
    Touch Points
    -
    Touch Panel
    4-wire Resistive Touch, F/G
    Mounting :
    Rear mounting holes (4-Ф2.4)
    Other Spec :
    Weight
    200g (Typ.)
    Treatment
    Antiglare

    HITACHI TX14D10VM1BPA Optical Details

    Basic Information :
    Luminance(cd/m²)
    280 (Typ.)
    Contrast Ratio
    350:1 (Typ.) (Transmissive)
    Viewing Angle
    70/70/70/70 (Typ.)(CR≥5)
    Display Mode
    TN, Normally White, Transmissive
    Best View on
    12 o'clock
    Response(ms)
    45 (Typ.)(Tr+Td)
    Color Performance :
    White Coordinate
    Wx:0.330; Wy:0.350
    Display Colors
    262K (6-bit)
    Color Temperature
    5598K
    White Uniformity
    1.33 (Max.)(9 points)

    HITACHI TX14D10VM1BPA Electronics Details

    Frame Rate :
    60Hz
    Reverse Scan :
    Yes (U/D, L/R)
    Total Consumption:
    1.479W (Typ.)

    HITACHI TX14D10VM1BPA Interface Detail

    Signal Electrical :
    Voltage Supply
    3.3V (Typ.)
    Current Supply
    145/174mA (Typ./Max.)
    Consumption
    0.479W (Typ.)
    Signal Type :
    LVDS (1 ch, 6-bit)
    Logic Voltage
    -
    Interface Features :
    Position
    -
    Type
    Connector
    Interface Detail :
    Brand
    Model
    Pitch
    Pins
    Quantity
    Pin Configuration
    JAE
    FI-SEB20P-HF13E-E1500
    1.25 mm
    20 pins
    1 pcs
    LVDS-20P1C6B-005B

    HITACHI TX14D10VM1BPA Backlight Details

    Backlight Features :
    Type
    WLED
    Quantity
    3S7P
    Position
    Edge light type
    Replacement
    -
    Shape
    Array
    Life Time
    40K(Typ.) (Hours)
    Interface Features :
    Position
    -
    Type
    Connector
    Interface Detail :
    Brand
    Model
    Pitch
    Pins
    Quantity
    Pin Configuration
    JST
    BHR-03VS-1
    4.0 mm
    3 pins
    1 pcs
    BDE-3PINS-VNG
    Backlight Driver :
    With LED Driver
    Driver Electrical :
    Voltage Supply
    12.0V (Typ.)
    Current Supply
    84/91mA (Typ./Max.)
    Consumption
    1.0W (Typ.)
