    1920×1920RGB 17INCH 600CD/M2 AUO TFT LCD WLED EDP 16.32W G170HAN01.0

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G170HAN01.0
    Certification : ISO9001
    Price :
    Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROW
    Supply Ability : 1117PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    1920×1920RGB 17INCH 600CD/M2 AUO TFT LCD WLED EDP 16.32W G170HAN01.0

    AUO G170HAN01.0 Application Features

    Basic Information :BrandModelTypeModel Alias
    G170HAN01.0a-Si TFT-LCD , LCM-
    Reliability :RoHSOperating TemperatureStorage TemperatureVibration Resistance
    -20 ~ 60 °C-20 ~ 70 °C-
    Designed For :

      AUO G170HAN01.0 Mechanical Features

      Panel Size :17.0 inch
      Pixel Features :ResolutionPixel ArrangementDot Pitch (W×H)Pixel Pitch (W×H)
      1920(RGB)×1920RGB Vertical Stripe0.053×0.159 mm0.159×0.159 mm [159PPI]
      Mechanical Size :Active Area (W×H)Bezel Area (W×H)Outline Dimension (W×H)Outline Depth
      305.28×305.28 mm-325.01×319.33 mm5.8/12.2 (Typ./Max.) mm
      Outline Features :Form StyleAspect RatioOrientationShape Style
      Flat Rectangle1:1 (W : H)Landscape type
      Fixation :Rear mounting holes (6-M3); Side mounting holes (4-M3) on left, right slugs
      Other Features :Panel CoverWeightSurface
      -1.20Kgs (Max.)Antiglare, Hard coating (3H)

      AUO G170HAN01.0 Optical Features

      Basic Information :BrightnessOperating ModeContrast Ratio
      600 cd/m² (Typ.)AHVA, Normally Black, Transmissive1000:1 (Typ.) (Transmissive)
      Viewing Angle(L/R/U/D)Viewing DirectionResponse Speed
      89/89/89/89 (Typ.)(CR≥10)Symmetry13/12 (Typ.)(Tr/Td) (ms)
      Dispaly Color :Color TemperatureColor AmountWhite color Chromaticity
      6485K16.7M (8-bit)X:0.313; Y:0.329
      1931 Color Gamlt :NTSC RatiosRGB CoverageAdobe RGB Coverage
      71%99%74%
      DCI-P3 CoverageRec.2020 CoverageRemarks
      74%53%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
      Luminance Variation :1.25/1.33 (Typ./Max.)(5 points)

      AUO G170HAN01.0 Electronics Features

      Power Consumption :16.32W (Typ.)
      Frame Rate :60Hz
      Reverse Scan :No

      AUO G170HAN01.0 Interface Features

      Signal Electrical :Current InputVoltage InputConsumption
      1.36A (Typ.)12.0V (Typ.)16.32/17.95W (Typ./Max.)
      Interface Features :PositionTypeInterface
      Down middle of panelConnectoreDP (4 Lanes), eDP1.3
      Signal Interface :BrandModelAmountPin PitchPinsPin Assignment
      JAEHD1S040HA11 pcs0.5 mm40 pins

      AUO G170HAN01.0 Backlight Features

      Backlight Features:TypePositionShapeAmountLife(Hours)Replacement
      WLEDEdge light type6 strings9S6P50K(Min.)-
      Interface Features :PositionTypeWLED Driver
      -Included in panel signal interfaceWith LED Driver

      FAQ:


      Q1: What's the quality of your LCD Panel?


      A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.


      Q2: What is your return and refund policy?


      A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.


      Q3: How long is the lead time?


      A: The lead time is about 1-3 working days after receipt of payment.


      Q4: How can I get the quotation?


      A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
