AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY

Product Categories

Sapientia Display Co.,LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Buy cheap AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY from wholesalers

Buy cheap AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY from wholesalers

AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	Mitsubishi
Model Number :	AA121XK01
Certification :	ISO9001
Price :	USD95
Payment Terms :	TT/PAYPAL/WESTERN UNION/ESCROW
Supply Ability :	1000PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY

Mitsubishi AA121XK01 Application Features

Basic Information :	Brand Name	Model Name 0 Compatible	Type	Model Alias
Basic Information :		AA121XK01	a-Si TFT-LCD , LCM	-
Maximum Ratings :	RoHS	Operating Temperature	Storage Temperature	Vibration Level
Maximum Ratings :		-30 ~ 80 °C	-30 ~ 80 °C	-

Mitsubishi AA121XK01 Mechanical Features

Screen Size :	12.1"
Pixel Features :	Pixel Number	Pixel Format	Dot Pitch (H×V)	Pixel Pitch (H×V)
Pixel Features :	1024(RGB)×768, XGA	RGB Vertical Stripe	0.080×0.240 mm	0.240×0.240 mm [105PPI]
Mechanical Size :	Display Area (H×V)	Bezel Opening (H×V)	Overall Dimension (H×V)	Overall Depth
Mechanical Size :	245.76×184.32 mm	249.0×187.5 mm	280×210 mm	12.0 (Typ.) mm
Outline Features :	Form Shape	Aspect Ratio (H:V)	Orientation	Shape Style
Outline Features :	Flat Rectangle	4:3	Landscape type
Other Spec :	Mass	Panel Cover	Surface Treatment
Other Spec :	750g (Typ.)	-	Antiglare, Hard coating (3H)

Mitsubishi AA121XK01 Optical Features

Basic Information :	Luminance	Work Mode	Contrast Ratio
	500 cd/m² (Typ.)	TN, Normally White, Transmissive	600:1 (Typ.) (Transmissive)
	Good View at	Viewing Angle	Response Time
	6 o'clock	80/80/60/80 (Typ.)(CR≥10)	6/19 (Typ.)(Tr/Td) (ms)
Dispaly Color :	Color Temperature:	Support Color	Color Coordinate
Dispaly Color :	6485K	262K/16.7M (6-bit / 8-bit)	X:0.313; Y:0.329
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	39%	55%	41%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	41%	29%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Mitsubishi AA121XK01 Electronics Features

Refresh Rate :	60Hz
Reverse Scan :	Yes (180°)
Power Consumption :	6.9W (Typ.)

Mitsubishi AA121XK01 Backlight Features

Back-light Features:	Type	Position	Life(Hours)	Amount	Shape	Replacement
Back-light Features:	WLED	Edge light type (Top side)	100K(Typ.)	2 strings	2 strings	Replaceable
WLED Electrical :	Input Voltage		Input Current			Power Consumption
WLED Electrical :	24.0/31.1V (Typ./Max.)		120/130mA (Typ./Max.)
Interface Features :	WLED Driver State			Physical Type		Interface Position
Interface Features :	No			Connector		-
Interface Detail	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail	JST	SM06B-SHLS-TF(LF)(SN)	1 pcs	6 pins	1.0 mm	BLE-6PINS-NNCAAC

Mitsubishi AA121XK01 Interface Features

Signal Electrical :	Input Voltage		Input Current			Power Consumption
Signal Electrical :	3.3V (Typ.)		320/600mA (Typ./Max.)			-
Interface Features :	Signal Type			Physical Type		Interface Position
Interface Features :	LVDS (1 ch, 6/8-bit)			Connector		-
Interface Detail :	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail :	JAE	FI-SE20P-HFE	1 pcs	20 pins	1.25 mm	LVDS-20P1C8B-010H

AA121XK01 Mitsubishi 12.1INCH 1024×768 500CD/M2 WLED LVDS INDUSTRIAL LCD DISPLAY
