    C070VAN02.0 AUO 7INCH 800×480RGB 1000CD/M2 WLED TTL Operating Temp.: -30 ~ 85 °CINDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : AUO
    Model Number : C070VAN02.0
    Certification : ISO9001
    Price :
    Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROW
    Supply Ability : 100PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    C070VAN02.0 AUO 7INCH 800×480RGB 1000CD/M2 WLED TTL Operating Temp.: -30 ~ 85 °CINDUSTRIAL LCD DISPLAY

    AUO C070VAN02.0 Application Features

    Basic Information :ManufacturerPanel ModelPanel TypeAlias
    C070VAN02.0a-Si TFT-LCD , LCM-
    Environment :RoHS StateOperating Temp.Storage Temp.Vibration Level
    -30 ~ 85 °C-40 ~ 95 °C2.9G (28.4 m/s²)

    AUO C070VAN02.0 Optical Features

    Basic Information :Luminance (cd/m²)Viewing Angle (L/R/U/D)Response Time (ms)
    1000 (Typ.)80/80/80/80 (Typ.)(CR≥100)9/11 (Typ.)(Tr/Td)
    Best View onDisplay ModeContrast Ratio
    SymmetryAHVA, Normally Black, Transmissive1000 : 1 (Typ.) (Transmissive)
    Dispaly Color :Color TemperatureDisplay ColorsWhite Coordinate
    -262K/16.7M (6-bit / 8-bit)-
    Performance :3D TechSunlight VisibilityReflectance
    -Sunlight Readable-

    AUO C070VAN02.0 Mechanical Features

    Panel Size :7.0"
    Pixel Features :Pixel FormatPixel ConfigurationPixel Pitch (mm)Dot Pitch (mm)
    800×480(RGB) [WVGA]RGB Horizontal Stripe0.1905×0.1905 [133PPI]0.1905×0.0635
    Mechanical Size :Active Area (mm)Bezel Area (mm)Outline Dimension (mm)Outline Depth (mm)
    152.4(H) × 91.44(V)-167.3(H) × 109.2(V)7.95 (Typ.) mm
    Outline Features :Form FactorOrientationAspect RatioShape Style
    Flat RectangleLandscape type15:9 (H:V)
    Mounting :Rear mounting Pole (4 pcs)
    Other Detail :WeightPanel CoverTreatment
    174±17g-

    Antiglare


    AUO C070VAN02.0 Electronics Features

    Reverse Scan :Yes (U/D, L/R)
    Vertical Frequency :60Hz

    AUO C070VAN02.0 Backlight Features

    Lamp Features:TypePositionQuantityShapeLife(Hours)Lamp Exchange
    WLEDEdge light type--20K(Typ.)-
    Interface Features :PositionBacklight DriverType
    -NoFPC

    AUO C070VAN02.0 Interface Features

    Panel Driving Electrical :Voltage SupplyCurrent SupplyPower
    3.3/13/20/-8V (Typ.)(VDD/AVDD/VGH/VGL)14/22/1.17/1.07A (Typ.)(IDD/AIDD/IGH/IGL)-
    Voltage for Display Signals :0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD
    Interface Features :PositionSignalType
    -Parallel RGB (1 ch, 6/8-bit) + SPIFPC
    FPC Detail :BrandModelPin PitchPin AmountQuantityConfiguration
    0.5 mm50 pins1 pcs
