1. HIGHEST QUALITY STANDARD DISPLAYS:
As a distributor,Sapientia display provides technical support for
the development of every type and class of LCD, from the design
stage right through to the production phase, while guaranteeing the
highest quality standards.
Our products can be customized for various applications and market
sectors, including (but not limited to): automotive, medical,
building automation, white goods, digital signage, security,
transportation and industrial.
2. AUO G084SN05 V9 Mechanical Details
| Pixel Features : | Pixel Format | 800(RGB)×600 [SVGA] | Dot Pitch | 0.071×0.213 mm (H×V) |
|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.213×0.213 mm (H×V) [119PPI] |
| Mechanical Size : | Display Area | 170.4×127.8 mm (H×V) | Bezel Area | 174.15×131.2 mm (H×V) |
|---|
| Outline Dim. | 203×142.5 mm (H×V) | Outline Depth | 8.0 (Max.) mm |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
|---|
| Aspect Ratio | 4:3 (H:V) | Shape Style | |
| Holes & Brackets : | Face mounting holes (2-Φ3.0, 2-R1.5) on left, right bezel |
|---|
| Other Features : | Weight | 250g (Typ.) | Surface | Antiglare, Hard coating (3H) |
|---|
3. AUO G084SN05 V9 Optical Details
| Basic Information : | Brightness | 450 cd/m² (Typ.) | Contrast Ratio | 600:1 (Typ.) (Transmissive) |
|---|
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive |
| Viewing Direction | 6 o'clock | Response Time | 20/10 (Typ.)(Tr/Td) (ms) |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Color Numbers | 262K/16.2M (6-bit / 6-bit + FRC) |
|---|
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points)  |
| 1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 72% coverage |
|---|
| Adobe RGB | 54% coverage | DCI-P3 | 54% coverage |
| Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020 |
4. AUO G084SN05 V9 Backlight Details
| Back-light Features: | Lamp Shape | 2 strings | Lamp Type | WLED | Life Time | 50K(Min.) (Hours) |
|---|
| Replacement | Replaceable | Amount | 2 strings | Position | Edge light type (Bottom side) |
| Lamp Electrical : | Voltage Input | 19.2/21.9V (Typ./Max.) | Current Input | 50/52.5mA (Typ./Max.) |
|---|
| Consumption | 1.92W (Typ.) |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
|---|
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
|---|
| E&T | 3808K-F04N-02R | 1.25 mm | 4 pins | 1 pcs | |
| Driver Electrical : | Voltage Input | 10.8/12.0/12.6V (Min./Typ./Max.) | Current Input | 0.17A (Typ.) |
|---|
| Consumption | 2.04/2.14W (Typ./Max.) |
AUO G084SN05 V9 Electronics Details
| Frame Rate : | 60Hz |
|---|
| Reverse Scan : | Yes (U/D, L/R) |
|---|
| Power Consumption : | 2.94W (Typ.) |
|---|
AUO G084SN05 V9 Interface Details
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 270/330mA (Typ./Max.) |
|---|
| Consumption | 0.9/1.2W (Typ./Max.) |
| Signal Type : | LVDS (1 ch, 6/8-bit) | Signal Voltage | - |
|---|
| Interface Features : | Position | - | Type | Connector |
|---|
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
|---|
| HRS | DF19LA-20P-1H | 1 pcs | 20 pins | 1.0 mm | LVDS-20P1C8B-140A |
AUO G084SN05 V9 Backlight Details
| Backlight Features: | Shape | 2 strings | Type | WLED | Position | Edge light type (Bottom side) |
|---|
| Replacement | Replaceable | Quantity | 2 strings | Life Time | 50K(Min.) (Hours) |
| Lamp Electrical : | Voltage Supply | 19.2/21.9V (Typ./Max.) | Current Supply | 50/52.5mA (Typ./Max.) |
|---|
| Consumption | 1.92W (Typ.) |
| Interface Features : | Position | - | Type | Connector |
|---|
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
|---|
| E&T | 3808K-F04N-02R | 1 pcs | 4 pins | 1.25 mm | |
| Backlight Driver : | With LED Driver |
|---|
| Driver Electrical : | Voltage Supply | 10.8/12.0/12.6V (Min./Typ./Max.) | Current Supply | 0.17A (Typ.) |
|---|
| Consumption | 2.04/2.14W (Typ./Max.) |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical
detail, it features active area of 170.4(W)×127.8(H) mm, outline
size of 203(W)×142.5(H)×8(D) mm, viewing area size of
174.15(W)×131.2(H) mm, with surface treament of Antiglare, Hard
coating (3H), net weight of 250g (Typ.). As a TN, Normally White,
Transmissive LCM product, G084SN05 V9 can provides 450 cd/m²
display brightness 600:1 transimissive contrast ratio, 80/80/80/60
(Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6
o'clock , and response time of 20/10 (Typ.)(Tr/Td) ms. Gray scale
or the brightness of the sub-pixel is determined with a 6-bit /
6-bit + FRC gray scale signal for each dot, thus presenting a
palette of 262K/16.2M colors, also with performance of color gamut
45% (NTSC). This product adopted 2 strings WLED as it's backlight
systerm which was placed as Edge light type (Bottom side) and have
a working life time of 50K hours, With LED Driver. G084SN05 V9
utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm,
which connected by 20 pins Connector with power supply voltage of
3.3V (Typ.)
