    G190ETN01.0 AUO 19.0 INCH WLED Backlight,Upside I/F,Matte 12S4P WLED , 30K hours , Without Driver

    Ask Lasest Price
    Brand Name : AUO
    Model Number : G190ETN01.0
    Certification : ISO9001
    Price : USD68
    Payment Terms : TT/PAYPAL/WESTERN UNION/ESCROW
    Supply Ability : 200PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    G190ETN01.0 AUO 19.0 INCH WLED Backlight,Upside I/F,Matte 12S4P WLED , 30K hours , Without Driver

    AUO G190ETN01.0 Optical Details

    Basic Information :Luminance350 cd/m² (Typ.)Contrast Ratio1000 : 1 (Typ.) (Transmissive)
    Good View at-Response Speed3.6/1.4 (Typ.)(Tr/Td) (ms)
    Viewing Angle85/85/80/80 (Typ.)(CR≥10)Operating ModeTN, Normally White, Transmissive
    Color Performance :ChromaticityWx:0.313; Wy:0.329Support Color16.7M (6-bit + Hi-FRC)
    Color Temperature6485KWhite Uniformity1.25/1.33 (Typ./Max.)(9 points)
    1931 Color Gamlt :NTSC Ratio72%sRGB93% coverage
    Adobe RGB72% coverageDCI-P375% coverage
    Rec.202054% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    AUO G190ETN01.0 Mechanical Details

    Pixel Features :Number of Pixel1280(RGB)×1024 [SXGA]ArrangementRGB Vertical Stripe
    Dot Pitch(W×H)0.098×0.294 mmPixel Pitch(W×H)0.294×0.294 mm [86PPI]
    Physical Size :Active Viewing376.32(W)×301.056(H) mmOverall Dim.396(W)×324(H) mm
    Bezel Opening380.0(W)×305.08(H) mmOverall Depth11.7 (Max.) mm
    Outline Features :Form ShapeFlat RectangleOrientationLandscape type
    Aspect Ratio(W:H)5:4Shape Style
    Fixation :Side mounting holes (4-M3) on left, right bezel
    Other Detail :Mass1.80Kgs (Typ.)SurfaceAntiglare, Hard coating (3H)

    AUO G190ETN01.0 Lightting Details

    Lamp Features:Lamp Shape4 stringsLamp TypeWLEDPositionEdge light type (Bottom side)
    Exchange-Amount12S4PLife30K(Typ.) (Hours)
    Lamp Electrical :Input Current60mA (Typ.)Input Voltage41.0/43.2V (Typ./Max.)
    Consumption9.8W (Typ.)
    Interface Features :PositionPhysical TypeConnector
    Interface Detail :BrandModelAmountPin PitchPin AmountPin Assignment
    E&T3707K-S06N-01R1 pcs1.0 mm6 pinsBLE-6PINS-CCAACC
    Backlight Driver :No

    AUO G190ETN01.0 Application Features

    Basic Information :Brand NameModel NameTypeModel Alias
    G190ETN01.0a-Si TFT-LCD , LCM97.19G04.000
    Maximum Ratings :RoHSOperating TemperatureStorage TemperatureVibration Level
    0 ~ 50 °C-20 ~ 60 °C

    whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 376.32(W)×301.056(H) mm, outline size of 396(W)×324(H)×11.7(D) mm, viewing area size of 380.0(W)×305.08(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 1.80Kgs (Typ.). As a TN, Normally White, Transmissive LCM product, G190ETN01.0 can provides 350 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle , and response time of 3.6/1.4 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted 12S4P WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 30K hours, external backlight driver is additionally needed. G190ETN01.0 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.)
