TM050JDHG33 TIANMA 5.0" 720(RGB)×1280 600 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	TIANMA
Model Number :	TM050JDHG33
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	3000PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

TM050JDHG33 TIANMA 5.0" 720(RGB)×1280 600 cd/m² INDUSTRIAL LCD DISPLAY

TIANMA TM050JDHG33 Application Details

Basic Detail :	Manufacturer Model Name TM050JDHG33 Panel Type a-Si TFT-LCD , LCM Another Name - Panel Size 5.0 inch Designed For
Maximum Ratings :	OP Temperature -20 ~ 70 °C ST Temperature -30 ~ 80 °C RoHS Vibration Level -
Features :

TIANMA TM050JDHG33 Optical Details

Basic Detail :	Luminance 600 cd/m² (Typ.) Contrast Ratio 800:1 (Typ.) (Transmissive) Good View at Symmetry Response Speed 30 (Typ.)(Tr+Td) ms Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Operating Mode SFT, Normally Black, Transmissive
Color Performance :	Chromaticity Wx:0.312; Wy:0.341 Support Color 16.7M (8-bit) Color Temperature 6444K White Variation 1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 76% sRGB 98% coverage Adobe RGB 76% coverage DCI-P3 79% coverage Rec.2020 56% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020

TIANMA TM050JDHG33 Mechanical Details

Pixel Features :	Number of Pixel 720(RGB)×1280, WXGA Arrangement RGB Vertical Stripe Dot Pitch(W×H) 0.02875×0.08625 mm Pixel Pitch(W×H) 0.08625×0.08625 mm [294PPI]
Physical Size :	Active Viewing 62.1(W)×110.4(H) mm Overall Dim. 65.4(W)×118.9(H) mm Bezel Opening - Overall Depth 1.7±0.1 mm
Outline Features :	Form Shape Flat Rectangle Orientation Portrait type Aspect Ratio(W:H) 9:16 Shape Style
Other Detail :	Mass TBD Surface Clear, Hard coating

TIANMA TM050JDHG33 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	No
Driver IC :	COG Built-in ILI9881C

TIANMA TM050JDHG33 Interface Detail

Signal Electrical :	Input Current - Input Voltage 1.8/2.8V (Typ.)(VDDIO/VCC) Consumption - Signal Interface MIPI (4 data lanes)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment HRS DF30FC-34DP-0.4V 0.4 mm 34 pins 1 pcs

TIANMA TM050JDHG33 Lightting Details

Lamp Features :	Lamp Type WLED Amount 6S2P Position Edge light type Exchange - Lamp Shape 2 strings Lamp Life 20K(Typ.) (Hours)
Lamp Electrical :	Input Voltage 19.2V (Typ.) Input Current 20mA (Typ.) Consumption 0.77/1.23W (Typ./Max.)
Interface Features :	Position - Type Included in panel signal interface
Backlight Driver :	No

TIANMA TM050JDHG33 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	192 pcs / box	11.7 Kgs	544×365×250 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours
