TM022HDHT1-05 TIANMA 2.2" 240(RGB)×320 90 cd/m² INDUSTRIAL LCD DISPLAY

TIANMA TM022HDHT1-05 Application Details

Basic Detail :	Manufacturer		Model Name	TM022HDHT1-05 2 Compatible
	Panel Type	a-Si TFT-LCD , LCM	Another Name	-
	Panel Size	2.2 inch	Designed For
Maximum Ratings :	OP Temperature	-20 ~ 70 °C	ST Temperature	-30 ~ 80 °C

TIANMA TM022HDHT1-05 Optical Details

Basic Information :	Luminance	90 cd/m² (Typ.)	Contrast Ratio	120 : 1 (Typ.) (Transmissive)
	Good View at	12 o'clock	Response Speed	35 (Typ.)(Tr+Td) (ms)
	Viewing Angle	40/45/48/45 (Typ.)(CR≥10)	Operating Mode	ECB, Normally White, Transflective
Color Performance :	Chromaticity	Wx:0.310; Wy:0.300	Support Color	262K (6-bit)
Color Performance :	Color Temperature	6989K	White Uniformity	1.25 (Typ.)(9 points)
Dispaly Performance :	Outdoor Visibility	Sunlight Readable	Transmissivity	-
Dispaly Performance :	3D Tech	-	Reflectance	6.8% (Typ.)

TIANMA TM022HDHT1-05 Mechanical Details

Pixel Features :	Number of Pixel	240(RGB)×320 [QVGA]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.047×0.141 mm	Pixel Pitch(W×H)	0.141×0.141 mm [180PPI]
Physical Size :	Active Viewing	33.84(W)×45.12(H) mm	Overall Dim.	40.6(W)×56.6(H) mm
Physical Size :	Bezel Opening	36.04(W)×47.32(H) mm	Overall Depth	2.7 (Typ.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Portrait type
Outline Features :	Aspect Ratio(W:H)	3:4	Shape Style
Other Detail :	Mass	12.7g	Surface	Clear, Hard coating (3H)

TIANMA TM022HDHT1-05 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	No
Driver IC :	Built-in ILI9340
Time Controller (T-CON) :	Embedded T-CON

TIANMA TM022HDHT1-05 Interface Details

Signal Electrical :	Input Current	10mA (Typ.)		Input Voltage	2.8V (Typ.)(VDD)
Signal Electrical :	Consumption	-	Signal Interface	Parallel RGB (1 ch, 6-bit) + SPI
Logic Voltage for Signals :	0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD
Interface Features :	Position	-	Physical Type	FPC
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :			1 pcs	0.3 mm	39 pins

TIANMA TM022HDHT1-05 Lightting Details

Lamp Features:	Lamp Shape	1 string	Lamp Type	WLED	Position	Edge light type
Lamp Features:	Exchange	-	Amount	4S1P	Life	20K(Typ.) (Hours)
Lamp Electrical :	Input Current	20mA (Typ.)		Input Voltage	12.8V (Typ.)
Lamp Electrical :	Consumption	256mW (Typ.)
Interface Features :	Position	-	Physical Type	Included in signal interface
Backlight Driver :	No

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 33.84(W)×45.12(H) mm, outline size of 40.6(W)×56.6(H) mm, viewing area size of 36.04(W)×47.32(H) mm, with surface treament of Clear, Hard coating (3H), net weight of 12.7g. As a ECB, Normally White, Transflective LCM product, TM022HDHT1-05 can provides 90 cd/m² display brightness 120:1 transimissive contrast ratio, 40/45/48/45 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 35 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors, also with performance of color gamut 30% (NTSC). This product adopted 4S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. TM022HDHT1-05 utilizes Parallel RGB (1 ch, 6-bit) + SPI as it's signal inputting systerm, which connected by 39 pins FPC with power supply voltage of 2.8V (Typ.)(VDD).
