TM084SDHG01-00 TIANMA 8.4" 800(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	TIANMA
Model Number :	TM084SDHG01-00
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	3000PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

TM084SDHG01-00 TIANMA 8.4" 800(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY

TIANMA TM084SDHG01-00 Application Features

Basic Information :	Brand Name	Model Name	Type	Model Alias
Basic Information :		TM084SDHG01-00	a-Si TFT-LCD , LCM	-
Maximum Ratings :	RoHS	Operating Temperature	Storage Temperature	Vibration Level
Maximum Ratings :		-20 ~ 70 °C	-30 ~ 80 °C

TIANMA TM084SDHG01-00 Mechanical Features

Screen Size :	8.4"
Pixel Features :	Pixel Number	Pixel Format	Dot Pitch (H×V)	Pixel Pitch (H×V)
Pixel Features :	800(RGB)×600, SVGA	RGB Vertical Stripe	0.071×0.213 mm	0.213×0.213 mm [119PPI]
Mechanical Size :	Display Area (H×V)	Bezel Opening (H×V)	Overall Dimension (H×V)	Overall Depth
Mechanical Size :	170.4×127.8 mm	173.8×131.2 mm	203×142.5 mm	5.7±0.5 mm
Outline Features :	Form Shape	Aspect Ratio (H:V)	Orientation	Shape Style
Outline Features :	Flat Rectangle	4:3	Landscape type
Other Spec :	Mass	Panel Cover	Surface Treatment
Other Spec :	TBD	-	Antiglare

TIANMA TM084SDHG01-00 Optical Features

Basic Information :	Luminance	Work Mode	Contrast Ratio
	250 cd/m² (Typ.)	TN, Normally White, Transmissive	500:1 (Typ.) (Transmissive)
	Good View at	Viewing Angle	Response Time
	6 o'clock	70/70/60/70 (Typ.)(CR≥10)	25 (Typ.)(Tr+Td) (ms)
Dispaly Color :	Color Temperature:	Support Color	Color Coordinate
Dispaly Color :	6638K	262K/16.7M (6-bit / 6-bit + Hi-FRC)	X:0.310; Y:0.330
White Uniformity :	1.33 (Typ.)(9 points)

TIANMA TM084SDHG01-00 Electronics Features

Refresh Rate :	60Hz
Reverse Scan :	Yes (U/D, L/R)

TIANMA TM084SDHG01-00 Backlight Features

Back-light Features:	Type	Position	Life(Hours)	Amount	Shape	Replacement
Back-light Features:	WLED	Edge light type	50K(Typ.)	9S3P	Array	-
Interface Features :	WLED Driver State			Physical Type		Interface Position
Interface Features :	With LED Driver			Connector		-
Interface Detail	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail	E&T	3808K-F04N-02R	1 pcs	4 pins	1.25 mm
WLED Driver Electrical :	Input Voltage		Input Current			Power Consumption
WLED Driver Electrical :	12.0±0.5V		TBD			TBD

TIANMA TM084SDHG01-00 Interface Features

Signal Electrical :	Input Voltage		Input Current			Power Consumption
Signal Electrical :	3.3V (Typ.)		TBD			TBD
Interface Features :	Signal Type			Physical Type		Interface Position
Interface Features :	LVDS (1 ch, 6/8-bit)			Connector		-
Interface Detail :	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail :	STARCONN	107A20-0021RA-G3-R	1 pcs	20 pins	1.0 mm	LVDS-20P1C8B-140A

whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 170.4(W)×127.8(H) mm, outline size of 203(W)×142.5(H)×6.2(D) mm, viewing area size of 173.8(W)×131.2(H) mm, with surface treament of Antiglare, net weight of TBD. As a TN, Normally White, Transmissive LCM product, TM084SDHG01-00 can provides 250 cd/m² display brightness 500:1 transimissive contrast ratio, 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted 9S3P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, With LED Driver. TM084SDHG01-00 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.)
