TM020HDH03 TIANMA 2.0 inch 240(RGB)×320 200 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	TIANMA
Model Number :	TM020HDH03
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Delivery Time :	1-2 DAYS
Supply Ability :	5000PCS

Add to Cart

Product Details
Company Profile

TM020HDH03 TIANMA 2.0 inch 240(RGB)×320 200 cd/m² INDUSTRIAL LCD DISPLAY

TIANMA TM020HDH03 Application Details

Basic Info :	Panel Brand		Panel Model	TM020HDH03
	Diagonal Size	2.0"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	-20 ~ 70 °C	Storage Temp.	-30 ~ 80 °C
Reliability :	RoHS State		Vibration Rating	-
Specific Features :

TIANMA TM020HDH03 Mechanical Details

Pixel Features :	Pixel Format	240(RGB)×320 [QVGA]	Dot Pitch	0.042×0.126 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.126×0.126 mm (H×V) [201PPI]
Mechanical Size :	Display Area	30.24×40.32 mm (H×V)	Bezel Area	-
Mechanical Size :	Outline Dim.	44.04×49.75 mm (H×V)	Outline Depth	2.45±0.1 mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Portrait type
Outline Features :	Aspect Ratio	3:4 (H:V)	Shape Style
Other Features :	Weight	TBD	Surface	Clear, Hard coating (3H

TIANMA TM020HDH03 Optical Details

Basic Information :	Brightness	200 cd/m² (Typ.)	Contrast Ratio	350:1 (Typ.) (Transmissive)
	Viewing Angle	60/60/55/60 (Typ.)(CR≥10)	Optical Mode	TN, Normally White, Transmissive
	Viewing Direction	9 o'clock	Response Time	25 (Typ.)(Tr+Td) (ms)
Color Performance :	Chromaticity	Wx:0.297; Wy:0.319	Color Numbers	65K/262K
Color Performance :	Color Temperature	7564K	White Uniformity	-
1931 Color Gamlt :	NTSC Ratio	50%	sRGB	71% coverage
	Adobe RGB	52% coverage	DCI-P3	52% coverage
	Rec.2020	37% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM020HDH03 Electronics Details

D-IC Detail :	COG Built-in ILI9335

TIANMA TM020HDH03 Backlight Details

Back-light Features:	Lamp Shape	Parallel	Lamp Type	WLED	Life Time	-
Back-light Features:	Replacement	-	Amount	1S3P	Position	Edge light type
Lamp Electrical :	Voltage Input	3.2V (Typ.)		Current Input	15mA (Typ.)
Lamp Electrical :	Consumption	144mW (Typ.)
Interface Features :	Type	Included in panel signal interface	Position	-	Lamp Driver	No

TIANMA TM020HDH03 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	768 pcs / box	TBD	544×365×250 mm

TIANMA TM020HDH03 Interface Details

Signal Systerm :	CPU			Logic Voltage	-
Signal Electrical :	Voltage Input	2.8V (Typ.)		Current Input	4.6mA (Typ.)
Interface Features :	Type	FPC	Position	-
FPC Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
FPC Detail :			0.8 mm	37 pins	1 pcs
