TM035KBH11 TIANMA 3.5 inch 320(RGB)×240 350cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	TIANMA
Model Number :	TM035KBH11
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	5000PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

TM035KBH11 TIANMA 3.5 inch 320(RGB)×240 350cd/m² INDUSTRIAL LCD DISPLAY

TIANMA TM035KBH11 Packing Features

Package Carton :	Amount	Weight	Carton Size
Package Carton :	168 pcs / box	10.617±5% Kgs	530×350×250 mm (L×W×H)

TIANMA TM035KBH11 Backlight Features

Backlight Features:	Type	Position	Shape	Amount	Life(Hours)	Replacement
Backlight Features:	WLED	Edge light type	1 string	6S1P	-	-
WLED Electrical :	Current Input		Voltage Input			Consumption
WLED Electrical :	20/25mA (Typ./Max.)		19.2/21.6V (Typ./Max.)			384mW (Typ.)
Interface Features :	Position	Type	WLED Driver
Interface Features :	-	Included in panel signal interface	No

TIANMA TM035KBH11 Interface Features

Signal Electrical :	Current Input		Voltage Input			Consumption
Signal Electrical :	-		3.3V (Typ.)			35/50mW (Typ./Max.)
Voltage for Display Signals :	0≤VIL≤0.2VCC; 0.8VCC≤VIH≤VCC
Interface Features :	Position	Type	Interface
Interface Features :	-	FPC	Digital RGB (8/24-bit) + SPI, CCIR601/656
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pins	Pin Assignment
Signal Interface :			1 pcs	0.5 mm	54 pins

TIANMA TM035KBH11 Electronics Features

Frame Rate :	60Hz
Reverse Scan :	No
D-IC Detail :	Built-in NT39016D
Time Controller (T-CON) :	Embedded T-CON

TIANMA TM035KBH11 Optical Features

Basic Information :	Brightness	Operating Mode	Contrast Ratio
	350 cd/m² (Typ.)	TN, Normally White, Transmissive	400:1 (Typ.) (Transmissive)
	Viewing Angle(L/R/U/D)	Viewing Direction	Response Speed
	70/70/60/70 (Typ.)(CR≥10)	12 o'clock	20 (Typ.)(Tr+Td) (ms)
Dispaly Color :	Color Temperature	Color Amount	White color Chromaticity
Dispaly Color :	6090K	16.7M (6-bit + Dithering)	X:0.320; Y:0.335
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	52%	72%	54%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	54%	39%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation :	1.25 (Typ.)(9 points)

TIANMA TM035KBH11 Mechanical Features

Panel Size :	3.5 inch
Pixel Features :	Resolution	Pixel Arrangement	Dot Pitch (W×H)	Pixel Pitch (W×H)
Pixel Features :	320(RGB)×240, QVGA	RGB Vertical Stripe	0.073×0.219 mm	0.219×0.219 mm [115PPI]
Mechanical Size :	Active Area (W×H)	Bezel Area (W×H)	Outline Dimension (W×H)	Outline Depth
Mechanical Size :	70.08×52.56 mm	72.08×54.56 mm	76.9×63.9 mm	4.0±0.2 mm
Outline Features :	Form Style	Aspect Ratio	Orientation	Shape Style
Outline Features :	Flat Rectangle	4:3 (W : H)	Landscape type
Touchscreen :	Touch Points	TP Controller	Signal Type	Touch Tech
Touchscreen :	-	Without touch controller	-	4-wire Resistive Touch
Other Features :	Panel Cover	Weight	Surface
Other Features :	-	40.6g	Antiglare, Hard coating (3H

TIANMA TM035KBH11 Application Features

Basic Information :	Brand	Model	Type	Model Alias
Basic Information :		TM035KBH11	a-Si TFT-LCD , LCM	-
Reliability :	RoHS	Operating Temperature	Storage Temperature	Vibration Resistance
Reliability :		-20 ~ 60 °C	-30 ~ 70 °C	-
Designed For :
Specific Features :
Remarks :	3 in 1 FPC; Down side FPC (37.00mm length)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
