G057AGE-T01 Innolux 5.7" 320(RGB)×240 500 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	INNOLUX
Model Number :	G057AGE-T01
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	500PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

G057AGE-T01 Innolux 5.7" 320(RGB)×240 500 cd/m² INDUSTRIAL LCD DISPLAY

Innolux G057AGE-T01 Application Details

Basic Information :	Brand G057AGE-T01Model Type a-Si TFT-LCD , LCM Used For 5.7 inchScreen Size Alias -
Environment :	Storage Temp. -30 ~ 85 °C Operating Temp. -30 ~ 85 °C RoHS 1.5G (14.7 m/s²)Vibration

Innolux G057AGE-T01 Mechanical Details

Pixel Features :	Resolution 320(RGB)×240, QVGA Dot Pitch(mm) 0.120×0.360 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.360×0.360 (H×V) [70PPI]
Mechanical Size :	Active Area(mm) 115.2(H) × 86.4(V) Bezel Area(mm) 118.2(H) × 89.4(V) Outline Dim.(mm) 144(H) × 104.6(V) Depth(mm) 12.3±0.5
Outline Features :	Form Style Flat Rectangle Shape Style Aspect Ratio 4:3 (H:V) Orientation Landscape type
Mounting :	Side mounting holes (4-Φ2.6); Rear mounting holes (4-Φ2.6)
Other Spec :	Weight 155/170g (Typ./Max.) Treatment Antiglare (Haze 25%)

Innolux G057AGE-T01 Optical Details

Basic Information :	Luminance(cd/m²) 500 (Typ.) Contrast Ratio 800:1 (Typ.) (Transmissive) Viewing Angle 80/80/70/70 (Typ.)(CR≥10) Display Mode TN, Normally White, Transmissive Best View on - Response(ms) 15/35 (Typ.)(Tr/Td)
Color Performance :	White Coordinate Wx:0.313; Wy:0.329 Display Colors 262K (6-bit) Color Temperature 6485K White Uniformity 1.25/1.40 (Typ./Max.)(5 points)
1931 Color Gamlt :	NTSC Ratio 54% sRGB 75% coverage Adobe RGB 57% coverage DCI-P3 56% coverage Rec.2020 40% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Innolux G057AGE-T01 Interface Detail

Signal Electrical :	Voltage Supply 3.3V (Typ.) Current Supply 151/181mA (Typ./Max.) Consumption 0.5W (Typ.)
Signal Type :	TTL (1 ch, 6-bit) Logic Voltage -
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration HRS FH12-33S-0.5SH 0.5 mm 33 pins 1 pcs DRGB-33P1C6B-020A

Innolux G057AGE-T01 Backlight Details

Backlight Features :	Type WLED Quantity - Position Edge light type Replacement - Shape - Life Time 50K(Min.) (Hours)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration JST SM06B-SRKS-G-TB 1.0 mm 6 pins 1 pcs
Backlight Driver :	With LED Driver
Driver Electrical :	Voltage Supply 12.0V (Typ.) Current Supply 0.23/0.26/0.28A (Min./Typ./Max.) Consumption 2.45W (Typ.)

Innolux G057AGE-T01 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	60 pcs / box	30 Kgs	540×450×275 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
