    T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : T-51963GD035J-MLW-AGN
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 1000PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY

    OPTREX T-51963GD035J-MLW-AGN Application Details

    Basic Information :BrandModelT-51963GD035J-MLW-AGN
    TypeLCM a-Si TFT-LCDUsed For
    Screen Size3.5"Alias-
    Environment :Storage Temp.-30 ~~ 70 °COperating Temp.-20 ~~ 70 °C
    RoHSVibration-

    OPTREX T-51963GD035J-MLW-AGN Mechanical Details

    Pixel Features :Resolution240(RGB)×320, QVGADot Pitch(mm)0.0745×0.2235 (H×V)
    Pixel FormatRGB Vertical StripePixel Pitch(mm)0.2235×0.2235 (H×V) [113PPI]
    Mechanical Size :Active Area(mm)53.64(H) × 71.52(V)Bezel Area(mm)-
    Outline Dim.(mm)65(H) × 86.2(V)Depth(mm)4.0 (Typ.)
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio3:4 (H:V)OrientationPortrait type
    Touch Panel :Touch Points1 pointTouch Panel4-wire Resistive Touch
    TP ControllerWithout touch controllerTouch Signal-
    Other Spec :Weight50.0g (Max.)Treatment-

    OPTREX T-51963GD035J-MLW-AGN Optical Details

    Basic Information :Luminance(cd/m²)130 (Typ.)Contrast Ratio70:1 (Typ.) (Transmissive) 5:1 (Typ.) (Reflective)
    Viewing Angle40/40/40/40 (Typ.)(CR≥10)Display ModeTN, Normally White, Transflective
    Best View on-Response(ms)30/50 (Typ.)(Tr/Td)
    Color Performance :White CoordinateX:0.320; Y:0.350Display Colors262K (6-bit)
    Color Temperature6022KWhite Uniformity1.43 (Max.)(5 points)
    Dispaly Performance :Outdoor VisibilitySunlight ReadableTransmissivity-
    3D Type-Reflectance20% (Typ.)

    OPTREX T-51963GD035J-MLW-AGN Electronics Details

    Frame Rate :60Hz
    Reverse Scan :Yes (U/D, L/R)
    Time Controller (T-CON) :Embedded T-CON

    OPTREX T-51963GD035J-MLW-AGN Interface Details

    Signal Electrical :Voltage Supply3.3/5.0/16.0/-12.0V (Typ.)(VDDD/VDDA/VGH/VGL)Current Supply1.6/8.0/0.05/0.05mA (Typ.)(IDDD/IDDA/IGH/IGL)
    Signal Type :CMOS (1 ch, 6-bit)Signal Voltage0≤VIL≤0.8V; 2.7V≤VIH≤3.6V
    Interface Features :Position-TypeFPC
    Interface Detail :BrandModelQuantityPinsPitchPin Configuration
    1 pcs50 pins0.5 mm

    OPTREX T-51963GD035J-MLW-AGN Backlight Details

    Backlight Features:Shape-TypeWLEDPositionEdge light type
    Replacement-Quantity-Life Time5K(Min.) (Hours)
    Lamp Electrical :Voltage Supply19.2/21.0V (Typ./Max.)Current Supply15/20mA (Typ./Max.)
    Consumption0.384W (Typ.)
    Interface Features :Position-TypeIncluded in panel signal interface
    Backlight Driver :No
