    T-55466D084J-LW-A-AAN Kyocera 8.4INCH LCM 800×600RGB 600NITS WLED LVDS INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : T-55466D084J-LW-A-AAN
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 200PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    T-55466D084J-LW-A-AAN Kyocera 8.4INCH LCM 800×600RGB 600NITS WLED LVDS INDUSTRIAL LCD DISPLAY

    OPTREX T-55466D084J-LW-A-AAN Application Features

    Basic Information :Brand NameModel Name 1 CompatibleTypeModel Alias
    T-55466D084J-LW-A-AANa-Si TFT-LCD , LCMAA084SB01
    Maximum Ratings :RoHSOperating TemperatureStorage TemperatureVibration Level
    -30 ~ 80 °C-30 ~ 80 °C-
    Application :

      OPTREX T-55466D084J-LW-A-AAN Mechanical Features

      Screen Size :8.4"
      Pixel Features :Pixel NumberPixel FormatDot Pitch (H×V)Pixel Pitch (H×V)
      800(RGB)×600, SVGARGB Vertical Stripe0.071×0.213 mm0.213×0.213 mm [119PPI]
      Mechanical Size :Display Area (H×V)Bezel Opening (H×V)Overall Dimension (H×V)Overall Depth
      170.4×127.8 mm174.9×132.2 mm199.5×149 mm11.5 (Typ.) mm
      Outline Features :Form ShapeAspect Ratio (H:V)OrientationShape Style
      Flat Rectangle4:3Landscape type
      Other Spec :MassPanel CoverSurface Treatment
      365g (Typ.)-Antiglare, Hard coating (3H)
      Holes & Brackets :Face mounting holes (4-Φ3.4), Side mounting holes (4-M2)

      OPTREX T-55466D084J-LW-A-AAN Optical Features

      Basic Information :LuminanceWork ModeContrast Ratio
      600 cd/m² (Typ.)TN, Normally White, Transmissive600:1 (Typ.) (Transmissive)
      Good View atViewing AngleResponse Time
      6 o'clock80/80/80/60 (Typ.)(CR≥10)4/12 (Typ.)(Tr/Td) (ms)
      Dispaly Color :Color Temperature:Support ColorColor Coordinate
      6485K262K/16.7M (6-bit / 6-bit + Hi-FRC)X:0.313; Y:0.329
      1931 Color Gamlt :NTSC RatiosRGB CoverageAdobe RGB Coverage
      39%54%41%
      DCI-P3 CoverageRec.2020 CoverageRemarks
      41%29%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
      White Uniformity :1.30 (Max.)(5 points)

      OPTREX T-55466D084J-LW-A-AAN Electronics Features

      Refresh Rate :60Hz
      Reverse Scan :Yes (180°)

      OPTREX T-55466D084J-LW-A-AAN Backlight Features

      Back-light Features:TypePositionLife(Hours)AmountShapeReplacement
      WLEDEdge light type (Bottom side)60K(Min.)2 strings2 stringsReplaceable
      WLED Electrical :Input VoltageInput CurrentPower Consumption
      30/36.5V (Typ./Max.)60/70mA (Typ./Max.)
      Interface Features :WLED Driver StatePhysical TypeInterface Position
      NoConnector-
      Interface DetailBrand NameModel NameAmountPinsPin PitchPin Configuration
      JSTSM06B-SHLS-TF1 pcs6 pins1.0 mmBLE-6PINS-NNCAAC

      OPTREX T-55466D084J-LW-A-AAN Interface Features

      Signal Electrical :Input VoltageInput CurrentPower Consumption
      3.3V (Typ.)350/540mA (Typ./Max.)-
      Interface Features :Signal TypePhysical TypeInterface Position
      LVDS (1 ch, 6/8-bit)Connector-
      Interface Detail :Brand NameModel NameAmountPinsPin PitchPin Configuration
      I-PEX20186-020E-11F1 pcs20 pins1.25 mmLVDS-20P1C8B-010H

        FAQ:
        Q1: What's the quality of your LCD Panel?
        A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
        Q2: What is your return and refund policy?
        A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
        Q3: How long is the lead time?
        A: The lead time is about 1-3 working days after receipt of payment.
        Q4: How can I get the quotation?
        A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.


        T-55466D084J-LW-A-AAN Kyocera 8.4INCH LCM 800×600RGB 600NITS WLED LVDS INDUSTRIAL LCD DISPLAYT-55466D084J-LW-A-AAN Kyocera 8.4INCH LCM 800×600RGB 600NITS WLED LVDS INDUSTRIAL LCD DISPLAY
