    STCG057QVLAB-G00 Kyocera 5.7INCH LCM 320×240RGB 300NITS WLED INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : STCG057QVLAB-G00
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 100PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    STCG057QVLAB-G00 Kyocera 5.7INCH LCM 320×240RGB 300NITS WLED INDUSTRIAL LCD DISPLAY

    Kyocera STCG057QVLAB-G00 Application Details

    Basic Detail :ManufacturerModel NameSTCG057QVLAB-G00
    Panel Typea-Si TFT-LCD , LCMAnother Name-
    Panel Size5.7 inchDesigned For
    Maximum Ratings :OP Temperature-20 ~ 70 °CST Temperature-30 ~ 80 °C
    Vibration Level-RoHS

    Kyocera STCG057QVLAB-G00 Optical Details

    Basic Information :Luminance300 cd/m² (Typ.)Contrast Ratio500 : 1 (Typ.) (Transmissive)
    Good View at-Response Speed10/25 (Typ.)(Tr/Td) (ms)
    Viewing Angle80/80/80/80 (Typ.)(CR≥5)Operating ModeTN, Normally White, Transmissive
    Color Performance :ChromaticityWx:0.330; Wy:0.370Support Color262K (6-bit)
    Color Temperature5570KWhite Uniformity-
    1931 Color Gamlt :NTSC Ratio60%sRGB75% coverage
    Adobe RGB60% coverageDCI-P362% coverage
    Rec.202045% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    Kyocera STCG057QVLAB-G00 Mechanical Details

    Pixel Features :Number of Pixel320(RGB)×240 [QVGA]ArrangementRGB Vertical Stripe
    Dot Pitch(W×H)0.120×0.360 mmPixel Pitch(W×H)0.360×0.360 mm [70PPI]
    Physical Size :Active Viewing115.2(W)×86.4(H) mmOverall Dim.144(W)×104.8(H) mm
    Bezel Opening118.4(W)×89.0(H) mmOverall Depth5.7/13.5 (Typ./Max.) mm
    Outline Features :Form ShapeFlat RectangleOrientationLandscape type
    Aspect Ratio(W:H)4:3Shape Style
    Fixation :Rear mounting poles (4-Φ2.6)
    Other Detail :Mass155g (Typ.)SurfaceGlare (Haze 0%)

    Kyocera STCG057QVLAB-G00 Electronics Details

    Reverse Scan :Yes (U/D, L/R)

    Kyocera STCG057QVLAB-G00 Interface Details

    Signal Electrical :Input Current80/110mA (Typ./Max.)Input Voltage3.3V (Typ.)
    Consumption-Signal InterfaceParallel RGB (1 ch, 6-bit)
    Interface Features :Position-Physical TypeConnector
    Signal Interface :BrandModelAmountPin PitchPin AmountPin Assignment
    Kyocera Elco08-6210-033-340-800+1 pcs0.5 mm33 pinsDRGB-33P1C6B-020A

      Kyocera STCG057QVLAB-G00 Lightting Details

      Lamp Features:Lamp Shape-Lamp TypeWLEDPositionEdge light type (Bottom side)
      Exchange-Amount-Life40K(Typ.) (Hours)
      Lamp Electrical :Input Current100mA (Typ.)Input Voltage12/13V (Typ./Max.)
      Interface Features :Position-Physical TypeConnector
      Interface Detail :BrandModelAmountPin PitchPin AmountPin Assignment
      JSTPHR-31 pcs2.0 mm3 pinsBLE-3PINS-ANC
      Backlight Driver :No

      FAQ:
      Q1: What's the quality of your LCD Panel?
      A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
      Q2: What is your return and refund policy?
      A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
      Q3: How long is the lead time?
      A: The lead time is about 1-3 working days after receipt of payment.
      Q4: How can I get the quotation?
      A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.


      STCG057QVLAB-G00 Kyocera 5.7INCH LCM 320×240RGB 300NITS WLED INDUSTRIAL LCD DISPLAYSTCG057QVLAB-G00 Kyocera 5.7INCH LCM 320×240RGB 300NITS WLED INDUSTRIAL LCD DISPLAY
