1024×600 RGB 500cd/m2 Tianma Industrial Panel TM090DDSG01 9.0in

Ask Lasest Price
Brand Name :	TIANMA
Model Number :	TM090DDSG01
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	100PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

1024×600 RGB 500cd/m2 Tianma Industrial Panel TM090DDSG01 9.0in

TIANMA TM090DDSG01 Application Details

Basic Detail :	Manufacturer		Model Name	TM090DDSG01
	Panel Type	a-Si TFT-LCD , LCM	Another Name	-
	Panel Size	9.0 inch	Designed For
Maximum Ratings :	OP Temperature	-20 ~ 70 °C	ST Temperature	-30 ~ 80 °C
Maximum Ratings :	Vibration Level	-	RoHS
Features :

TIANMA TM090DDSG01 Optical Details

Basic Information :	Luminance	500 cd/m² (Typ.)	Contrast Ratio	800 : 1 (Typ.) (Transmissive)
	Good View at	12 o'clock	Response Speed	25 (Typ.)(Tr+Td) (ms)
	Viewing Angle	70/70/50/70 (Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Color Performance :	Chromaticity	Wx:0.304; Wy:0.335	Support Color	262K/16.7M (6-bit / 8-bit)
Color Performance :	Color Temperature	6914K	White Uniformity	1.25/1.43 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	56%	sRGB	76% coverage
	Adobe RGB	59% coverage	DCI-P3	58% coverage
	Rec.2020	42% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

TIANMA TM090DDSG01 Mechanical Details

Pixel Features :	Number of Pixel	1024(RGB)×600 [WSVGA]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.064×0.19025 mm	Pixel Pitch(W×H)	0.192×0.19025 mm [132PPI]
Physical Size :	Active Viewing	196.608(W)×114.15(H) mm	Overall Dim.	211.1(W)×126.5(H) mm
Physical Size :	Bezel Opening	200.01(W)×117.55(H) mm	Overall Depth	5.7±0.3 mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio(W:H)	17:10	Shape Style
Other Detail :	Mass	TBD	Surface	Antiglare

TIANMA TM090DDSG01 Electronics Details

Refresh Rate :	60Hz
Reverse Scan :	Yes (U/D, L/R)

TIANMA TM090DDSG01 Interface Details

Signal Electrical :	Input Current	-		Input Voltage	3.3/10.6/23/-7V (Typ.)(VDD/AVDD/VGH/VGL)
Signal Electrical :	Consumption	-	Signal Interface	LVDS (1 ch, 6/8-bit)
Interface Features :	Position	-	Physical Type	FPC
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :			1 pcs	0.5 mm	40 pins

TIANMA TM090DDSG01 Lightting Details

Lamp Features:	Lamp Shape	Array	Lamp Type	WLED	Position	Edge light type
Lamp Features:	Exchange	-	Amount	3S10P	Life	20K(Typ.) (Hours)
Lamp Electrical :	Input Current	300mA (Typ.)		Input Voltage	9.6V (Typ.)
Lamp Electrical :	Consumption	2.88W (Typ.)
Interface Features :	Position	-	Physical Type	Connector
Interface Detail :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Interface Detail :	JST	BHSR-02VS-1	1 pcs	3.5 mm	2 pins	BLE-2PINS-AC
Backlight Driver :	No

TIANMA TM090DDSG01 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	50 pcs / box	530×350×288 mm	TBD
