    TCG075VG2AC-A02 Kyocera 7.5INCH LCM 640×480RGB 270NITS CCFL TTL INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : TCG075VG2AC-A02
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 50PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    TCG075VG2AC-A02 Kyocera 7.5INCH LCM 640×480RGB 270NITS CCFL TTL INDUSTRIAL LCD DISPLAY

    Kyocera TCG075VG2AC-A02 Application Features

    Basic Information :Brand NameModel NameTypeModel Alias
    TCG075VG2AC-A02a-Si TFT-LCD , LCM-
    Maximum Ratings :RoHSOperating TemperatureStorage TemperatureVibration Level
    ---

    Kyocera TCG075VG2AC-A02 Mechanical Features

    Screen Size :7.5"
    Pixel Features :Pixel NumberPixel FormatDot Pitch (H×V)Pixel Pitch (H×V)
    640(RGB)×480, VGARGB Vertical Stripe0.079×0.237 mm0.237×0.237 mm [107PPI]
    Mechanical Size :Display Area (H×V)Bezel Opening (H×V)Overall Dimension (H×V)Overall Depth
    151.68×113.76 mm156.3×118.4 mm184×139.8 mm12.7±0.5 mm
    Outline Features :Form ShapeAspect Ratio (H:V)OrientationShape Style
    Flat Rectangle4:3Landscape type
    Other Spec :MassPanel CoverSurface Treatment
    370g (Typ.)-Antiglare

    Kyocera TCG075VG2AC-A02 Optical Features

    Basic Information :LuminanceWork ModeContrast Ratio
    270 cd/m² (Typ.)TN, Normally White, Transmissive450:1 (Typ.) (Transmissive)
    Good View atViewing AngleResponse Time
    -80/80/70/70 (Typ.)(CR≥5)5/15 (Typ.)(Tr/Td) (ms)
    Dispaly Color :Color Temperature:Support ColorColor Coordinate
    -262K (6-bit)-

    Kyocera TCG075VG2AC-A02 Electronics Features

    Refresh Rate :60Hz
    Power Consumption :5.06W (Typ.)

    Kyocera TCG075VG2AC-A02 Backlight Features

    Back-light Features:TypePositionLife(Hours)AmountShapeReplacement
    CCFLEdge light type (Top and Bottom)54K(Typ.)2 pcsStraight-
    Interface Features :CCFL Driver StatePhysical TypeInterface Position
    NoConnector-

    Kyocera TCG075VG2AC-A02 Interface Features

    Interface Features :Signal TypePhysical TypeInterface Position
    Parallel RGB (1 ch, 6-bit)Connector-
