    TCG121XGLPAPNN-AN20-SA Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : TCG121XGLPAPNN-AN20-SA
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 100PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    TCG121XGLPAPNN-AN20-SA Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY

    Kyocera TCG121XGLPAPNN-AN20-SA Application Features

    Basic Information :BrandModelTypeModel Alias
    TCG121XGLPAPNN-AN20-SAa-Si TFT-LCD , LCM-
    Reliability :RoHSOperating TemperatureStorage TemperatureVibration Resistance
    -30 ~ 80 °C-30 ~ 80 °C-

    Kyocera TCG121XGLPAPNN-AN20-SA Mechanical Features

    Panel Size :12.1 inch
    Pixel Features :ResolutionPixel ArrangementDot Pitch (W×H)Pixel Pitch (W×H)
    1024(RGB)×768, XGARGB Vertical Stripe0.080×0.240 mm0.240×0.240 mm [105PPI]
    Mechanical Size :Active Area (W×H)Bezel Area (W×H)Outline Dimension (W×H)Outline Depth
    245.76×184.32 mm249.0×187.5 mm260.5×203.4 mm10.3±0.5 mm
    Outline Features :Form StyleAspect RatioOrientationShape Style
    Flat Rectangle4:3 (W : H)Landscape type
    Fixation :Side mounting holes (6-M3) on left, right bezel
    Other Features :Panel CoverWeightSurface
    -670gAntiglare

    Kyocera TCG121XGLPAPNN-AN20-SA Optical Features

    Basic Information :BrightnessOperating ModeContrast Ratio
    400 cd/m² (Typ.)AWV, Normally Black, Transmissive750:1 (Typ.) (Transmissive)
    Viewing Angle(L/R/U/D)Viewing DirectionResponse Speed
    85/85/85/85 (Typ.)(CR≥10)Symmetry18/12 (Typ.)(Tr/Td) (ms)
    Dispaly Color :Color TemperatureColor AmountWhite color Chromaticity
    7203K262K/16.2M (6-bit / 6-bit + FRC)X:0.300; Y:0.330
    1931 Color Gamlt :NTSC RatiosRGB CoverageAdobe RGB Coverage
    48%67%50%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    50%36%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    Kyocera TCG121XGLPAPNN-AN20-SA Electronics Features

    Frame Rate :60Hz
    Reverse Scan :Yes (180°)

    Kyocera TCG121XGLPAPNN-AN20-SA Interface Features

    Signal Electrical :Current InputVoltage InputConsumption
    300/390mA (Typ./Max.)3.3V (Typ.)-
    Interface Features :PositionTypeInterface
    -ConnectorLVDS (1 ch, 6/8-bit)
    Signal Interface :BrandModelAmountPin PitchPinsPin Assignment
    I-PEX20186-020E-11F1 pcs1.25 mm20 pinsLVDS-20P1C8B-010H

      Kyocera TCG121XGLPAPNN-AN20-SA Backlight Features

      Backlight Features:TypePositionShapeAmountLife(Hours)Replacement
      WLEDEdge light type--50K(Typ.)-
      Interface Features :PositionTypeWLED Driver
      -ConnectorWith LED Driver
      Interface DetailBrandModelAmountPin PitchPinsPin Assignment
      JSTSM06B-SHLS-G-TF(LF)(SN)1 pcs1.0 mm6 pins
      Driver Electrical :Current InputVoltage InputConsumption
      480/560mA (Typ./Max.)12.0V (Typ.)-

      FAQ:
      Q1: What's the quality of your LCD Panel?
      A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
      Q2: What is your return and refund policy?
      A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
      Q3: How long is the lead time?
      A: The lead time is about 1-3 working days after receipt of payment.
      Q4: How can I get the quotation?
      A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.


      TCG121XGLPAPNN-AN20-SA Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAYTCG121XGLPAPNN-AN20-SA Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY
