    TG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : Kyocera
    Model Number : TG035QVLQAANN-GN00
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW
    Supply Ability : 50PCS
    Delivery Time : 1-2day
    • Product Details
    • Company Profile

    TG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY

    Kyocera TG035QVLQAANN-GN00 Application Details

    Basic Information :BrandModelTG035QVLQAANN-GN00
    TypeLCM a-Si TFT-LCDUsed For



    Screen Size3.5"Alias-
    Environment :Storage Temp.-30 ~~ 80 °COperating Temp.-20 ~~ 70 °C
    RoHSVibration-

    Kyocera TG035QVLQAANN-GN00 Mechanical Details

    Pixel Features :Resolution320(LCR)×240, QVGADot Pitch(mm)0.0735×0.2205 (H×V)
    Pixel FormatLCR Vertical StripePixel Pitch(mm)0.2205×0.2205 (H×V) [115PPI]
    Mechanical Size :Active Area(mm)70.56(H) × 52.92(V)Bezel Area(mm)72.26(H) × 54.62(V)
    Outline Dim.(mm)76.9(H) × 63.9(V)Depth(mm)4.90±0.3
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio4:3 (H:V)OrientationLandscape type
    Other Spec :Weight40.0gTreatment-

    Kyocera TG035QVLQAANN-GN00 Optical Details

    Basic Information :Luminance(cd/m²)1200 (Typ.)Contrast Ratio1000:1 (Typ.) (Transmissive)
    Viewing Angle80/80/80/60 (Typ.)(CR≥10)Display ModeTN, Normally White, Transmissive
    Best View on12 o'clockResponse(ms)8/22 (Typ.)(Tr/Td)
    Color Performance :White CoordinateX:0.310; Y:0.310Display ColorsGrayscale (6-bit)
    Color Temperature6852KWhite Uniformity-
    Dispaly Performance :Outdoor VisibilitySunlight ReadableTransmissivity-

    Kyocera TG035QVLQAANN-GN00 Electronics Details

    Frame Rate :60Hz
    Reverse Scan :Yes (180°)

    Kyocera TG035QVLQAANN-GN00 Interface Details

    Signal Electrical :Voltage Supply3.3V (Typ.)Current Supply8.0/11.3mA (Typ./Max.)
    Signal Type :Parallel RGB (1 ch, 8-bit) + SPISignal Voltage0≤VIL≤0.3VDD; 0.8VDD≤VIH≤VDD
    Interface Features :Position-TypeFPC
    Interface Detail :BrandModelQuantityPinsPitchPin Configuration
    1 pcs50 pins0.5 mm

    Kyocera TG035QVLQAANN-GN00 Backlight Details

    Backlight Features:Shape2 stringsTypeWLEDPositionEdge light type
    Replacement-Quantity-Life Time60K(Typ.) (Hours)
    Lamp Electrical :Voltage Supply12.5/13.3V (Typ./Max.)Current Supply15mA (Typ.)
    Interface Features :Position-TypeIncluded in panel signal interface
    Backlight Driver :No

    FAQ:
    Q1: What's the quality of your LCD Panel?
    A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
    Q2: What is your return and refund policy?
    A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
    Q3: How long is the lead time?
    A: The lead time is about 1-3 working days after receipt of payment.
    Q4: How can I get the quotation?
    A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.


    TG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAYTG035QVLQAANN-GN00 Kyocera 3.5INCH LCM 320×240RGB 1200NITS WLED TTL INDUSTRIAL LCD DISPLAY
