LW550PUL-HLA1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

Ask Lasest Price
Brand Name :	LG Display
Model Number :	LW550PUL-HLA1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	100PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

LW550PUL-HLA1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY

LG Display LW550PUL-HLA1 Application Details

Basic Information :	Brand		Model	LW550PUL-HLA1
	Type	OLED AM-OLED	Used For
	Screen Size	55"	Alias	LW550PUL (HL)(A1)
Environment :	Storage Temp.	-20 ~~ 60 °C	Operating Temp.	0 ~~ 45 °C

LG Display LW550PUL-HLA1 Mechanical Details

Pixel Features :	Resolution	1920(RGBW)×1080, FHD	Dot Pitch(mm)	-
Pixel Features :	Pixel Format	RGBW Vertical Stripe	Pixel Pitch(mm)	0.630×0.630 (H×V) [40PPI]
Mechanical Size :	Active Area(mm)	1209.6(H) × 680.4(V)	Bezel Area(mm)	-
Mechanical Size :	Outline Dim.(mm)	1217.48(H) × 693.74(V)	Depth(mm)	1.03 (Typ.)
Outline Features :	Form Style	Curved Display	Outline Shape
Outline Features :	Aspect Ratio	16:9 (H:V)	Orientation	Landscape type
Other Spec :	Weight	2.40Kgs (Typ.)	Treatment	Hard coating (2H), Reflection 1.2% (Typ.)

LG Display LW550PUL-HLA1 Optical Details

Basic Information :	Luminance(cd/m²)	400 (Typ.)	Contrast Ratio	150000:1 (Typ.) (Transmissive)
	Viewing Angle	60/60/60/60 (Min.)	Display Mode	-
	Best View on	Symmetry	Response(ms)	1 (Typ.)(G to G); 8 (Typ.)(MPRT)
Color Performance :	White Coordinate	X:0.285; Y:0.294	Display Colors	1.07B (10-bit)
Color Performance :	Color Temperature	9246K	White Uniformity	1.25/1.43 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	89%	sRGB	100% coverage
	Adobe RGB	86% coverage	DCI-P3	93% coverage
	Rec.2020	67% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LW550PUL-HLA1 Interface Details

Signal Electrical :	Voltage Supply	12.0/24.0V (Typ.)(VDD/EVDD)		Current Supply	1.61/3.23A (Typ.)(IDD/EIDD)
Signal Electrical :	Consumption	19.32/77.52W (Typ.)(PDD/EPDD)
Signal Type :	V-by-One 8 lane			Signal Voltage	-
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
	YEONHO	20022WR-H14B2	1 pcs	14 pins	2.0 mm
	JAE	FI-RXE51S-HF	1 pcs	51 pins	0.5 mm

LG Display LW550PUL-HLA1 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	70 pcs / box	-	1440×1140×1085 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
