49" 1920×1080 57.0W 45PPI Tft Lcd Screen 400cd/m2 LC490DUE-FKM3

Ask Lasest Price
Brand Name :	LG Display
Model Number :	LC490DUE-FKM3
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	120PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

49" 1920×1080 57.0W 45PPI Tft Lcd Screen 400cd/m2 LC490DUE-FKM3

LG Display LC490DUE-FKM3 Application Features

Basic Information :	Brand Name	Model Name	Type	Model Alias
Basic Information :		LC490DUE-FKM3	a-Si TFT-LCD , LCM	LC490DUE (FK)(M3)
Maximum Ratings :	RoHS	Operating Temperature	Storage Temperature	Vibration Level
Maximum Ratings :		0 ~ 50 °C	-

LG Display LC490DUE-FKM3 Mechanical Features

Screen Size :	49"
Pixel Features :	Pixel Number	Pixel Format	Dot Pitch (H×V)	Pixel Pitch (H×V)
Pixel Features :	1920(RGB)×1080, FHD	RGB Vertical Stripe	0.18642×0.55926 mm	0.55926×0.55926 mm [45PPI]
Mechanical Size :	Display Area (H×V)	Bezel Opening (H×V)	Overall Dimension (H×V)	Overall Depth
Mechanical Size :	1073.78×604 mm	1076.8×607.0 mm	1106.17×640.23 mm	43.45 (Typ.) mm
Outline Features :	Form Shape	Aspect Ratio (H:V)	Orientation	Shape Style
Outline Features :	Flat Rectangle	16:9	Landscape type
Other Spec :	Mass	Panel Cover	Surface Treatment
Other Spec :	7.60/8.10Kgs (Typ./Max.)	-	Antiglare (Haze 3%), Hard coating (2H)

LG Display LC490DUE-FKM3 Optical Features

Basic Information :	Luminance	Work Mode	Contrast Ratio
	400 cd/m² (Typ.)	IPS, Normally Black, Transmissive	1100:1 (Typ.) (Transmissive)
	Good View at	Viewing Angle	Response Time
	Symmetry	89/89/89/89 (Min.)(CR≥10)	9 (Typ.)(G to G) (ms)
Dispaly Color :	Color Temperature:	Support Color	Color Coordinate
Dispaly Color :	9966K	16.7M (8-bit)	X:0.281; Y:0.288
1931 Color Gamlt :	NTSC Ratio	sRGB Coverage	Adobe RGB Coverage
	70%	94%	71%
	DCI-P3 Coverage	Rec.2020 Coverage	Remarks
	73%	52%	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Uniformity :	1.54 (Max.)(9 points)

LG Display LC490DUE-FKM3 Backlight Features

Back-light Features:	Type	Position	Life(Hours)	Amount	Shape	Replacement
Back-light Features:	WLED	Direct light type	50K(Typ.)	-	-	-
WLED Electrical :	Input Voltage		Input Current			Power Consumption
WLED Electrical :	67.2/76.8/86.4V (Min./Typ./Max.)		660±33mA			50.7/57.0W (Typ./Max.)
Interface Features :	WLED Driver State			Physical Type		Interface Position
Interface Features :	No			Connector		-
Interface Detail	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail		YW500-H02E	1 pcs	7 pins		BLE-7PINS-ANNNNNC

LG Display LC490DUE-FKM3 Interface Features

Signal Electrical :	Input Voltage		Input Current			Power Consumption
Signal Electrical :	12.7V (Typ.)		355/465mA (Typ./Max.)			4.5/5.9W (Typ./Max.)
Interface Features :	Signal Type			Physical Type		Interface Position
Interface Features :	LVDS (2 ch, 8-bit)			Connector		-
Interface Detail :	Brand Name	Model Name	Amount	Pins	Pin Pitch	Pin Configuration
Interface Detail :	JAE	FI-RXE51S-HF	1 pcs	51 pins	0.5 mm

LG Display LC490DUE-FKM3 Packing Features

Package Box :	Amount	Weight	Size (L×W×H)
Package Box :	14 pcs / box	-	1300×1140×825 mm (L×W×H)
