    99PPI 20.1" 1600x1200 Tft Lcd Screen 300cd/m2 LM201U04-SL02 89/89/89/89 (Typ.)(CR≥10)

    Ask Lasest Price
    Brand Name : LG. LCD
    Model Number : LM201U04-SL02
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 120PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    99PPI 20.1" 1600x1200 Tft Lcd Screen 300cd/m2 LM201U04-SL02 89/89/89/89 (Typ.)(CR≥10)

    LG. LCD LM201U04-SL02 Application Details

    Basic Info :Panel BrandPanel ModelLM201U04-SL02
    Diagonal Size20.1"Application
    Panel Typea-Si TFT-LCD , LCMModel AliasLM201U04 (SL)(02)
    Reliability :Operating Temp.0 ~ 50 °CStorage Temp.-20 ~ 60 °C
    RoHS StateVibration Rating-

    LG. LCD LM201U04-SL02 Mechanical Details

    Pixel Features :Pixel Format1600(RGB)×1200 [UXGA]Dot Pitch0.085×0.255 mm (H×V)
    ConfigurationRGB Vertical StripePixel Pitch0.255×0.255 mm (H×V) [99PPI]
    Mechanical Size :Display Area408×306 mm (H×V)Bezel Area413.0×311.0 mm (H×V)
    Outline Dim.432×331.5 mm (H×V)Outline Depth17.4/25.5 (Typ./Max.) mm
    Outline Features :Form FactorFlat RectangleOrientationLandscape type
    Aspect Ratio4:3 (H:V)Shape StyleNormal bezel
    Holes & Brackets :Side mounting holes (4-M3) on left, right bezel
    Other Features :Weight3.20Kgs (Typ.)SurfaceAntiglare (Haze 25%), Hard coating (3H)

    LG. LCD LM201U04-SL02 Optical Details

    Basic Information :Brightness300 cd/m² (Typ.)Contrast Ratio700:1 (Typ.) (Transmissive)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10)Optical ModeS-IPS, Normally Black, Transmissive
    Viewing DirectionSymmetryResponse Time7/9 (Typ.)(Tr/Td); 12 (Typ.)(G to G) (ms)
    Color Performance :ChromaticityWx:0.313; Wy:0.329Color Numbers16.7M (8-bit)
    Color Temperature6485KWhite Uniformity1.39 (Max.)(9 points)
    1931 Color Gamlt :NTSC Ratio72%sRGB94% coverage
    Adobe RGB75% coverageDCI-P375% coverage
    Rec.202054% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    LG. LCD LM201U04-SL02 Backlight Details

    Back-light Features:Lamp ShapeStraightLamp TypeCCFLLife Time45K(Min.) (Hours)
    Replacement-Amount6 pcsPositionEdge light type (Top and Bottom)
    Lamp Electrical :Voltage Input680/700/825V (Min./Typ./Max.)Current Input3.0/7.0/7.5mA (Min./Typ./Max.)
    Frequency40/50/80KHz (Min./Typ./Max.)Kick-off Voltage1150/1450V (Max.)(Ta=+25/0℃)
    Consumption29.4/32.3W (Typ./Max.)
    Interface Features :TypeConnectorPosition-Lamp DriverNo
    Interface Detail :BrandModelPin PitchPinsAmountConfiguration
    JSTBHSR-02VS-13.5 mm2 pins2 pcsBLL-2PINS-HL
    JSTBHR-05VS-14.0 mm5 pins2 pcsBLL-5PINS-HHNLL

    LG. LCD LM201U04-SL02 Interface Details

    Signal Systerm :LVDS (2 ch, 8-bit)Logic Voltage-
    Signal Electrical :Voltage Input20.0V (Typ.)Current Input280/360mA (Typ./Max.)
    Consumption5.58/7.2W (Typ./Max.)
    Interface Features :TypeConnectorPosition-
    Connector Detail :BrandModelPin PitchPinsAmountConfiguration
    JAEFI-XB30SRL-HF111.0 mm30 pins1 pcsLVDS-30P2C8B-030A

    LG. LCD LM201U04-SL02 Carton Details

    Package Carton :AmountNet WeightCarton Size (L×W×H)
    5 pcs / box-530×307×453 mm

    FAQ:
    Q1: What's the quality of your LCD Panel?
    A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
    Q2: What is your return and refund policy?
    A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
    Q3: How long is the lead time?
    A: The lead time is about 1-3 working days after receipt of payment.
    Q4: How can I get the quotation?
    A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
