    LM315QU1-SSA2 32.0" 7680x4320 Industrial TFT Display 400 cd/m² 89/89/89/89 (Typ.)(CR≥10)

    Ask Lasest Price
    Brand Name : LG Display
    Model Number : LM315QU1-SSA2
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 120PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    LM315QU1-SSA2 32.0" 7680x4320 Industrial TFT Display 400 cd/m² 89/89/89/89 (Typ.)(CR≥10)

    LG Display LM315QU1-SSA2 Application Details

    Basic Information :BrandModelLM315QU1-SSA2
    TypeLCM a-Si TFT-LCDUsed For
    Screen Size32.0"AliasLM315QU1 (SS)(A2)
    Environment :Storage Temp.-20 ~~ 60 °COperating Temp.0 ~~ 50 °C

    LG Display LM315QU1-SSA2 Mechanical Details

    Pixel Features :Resolution7680(RGB)×4320, QUHDDot Pitch(mm)0.0303×0.0909 (H×V)
    Pixel FormatRGB Vertical StripePixel Pitch(mm)0.0909×0.0909 (H×V) [279PPI]
    Mechanical Size :Active Area(mm)698.11(H) × 392.69(V)Bezel Area(mm)-
    Outline Dim.(mm)717.8(H) × 412.5(V)Depth(mm)10.8/17.1 (Typ./Max.)
    Outline Features :Form StyleFlat RectangleOutline Shape4-side borderless
    Aspect Ratio16:9 (H:V)OrientationLandscape type
    Mounting :Rear mounting holes
    Other Spec :Weight3.71/3.90Kgs (Typ./Max.)TreatmentHard coating (2H), Antireflection

    LG Display LM315QU1-SSA2 Optical Details

    Basic Information :Luminance(cd/m²)400 (Typ.)Contrast Ratio1300:1 (Typ.) (Transmissive)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10)Display ModeIPS, Normally Black, Transmissive
    Best View onSymmetryResponse(ms)14 (Typ.)(G to G)
    Color Performance :White CoordinateX:0.313; Y:0.329Display Colors1.07B (10-bit)
    Color Temperature6485KWhite Uniformity1.33 (Max.)(9 points)
    1931 Color Gamlt :NTSC Ratio109%sRGB100% coverage
    Adobe RGB100% coverageDCI-P399% coverage
    Rec.202081% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    LG Display LM315QU1-SSA2 Interface Details

    Signal Electrical :Voltage Supply10.0V (Typ.)Current Supply2.0/2.5A (Typ./Max.)
    Consumption20/25W (Typ./Max.)
    Signal Type :V-by-One 16 lane × 2chSignal Voltage-
    Interface Features :PositionTypeConnector
    Interface Detail :BrandModelQuantityPinsPitchPin Configuration
    UJUIS050-C51B-C39-A2 pcs51 pins0.5 mm
    UJUIS050-C41B-C39-A1 pcs41 pins0.5 mm

    LG Display LM315QU1-SSA2 Backlight Details

    Backlight Features:Shape4 stringsTypeWLEDPositionEdge light type
    Replacement-Quantity19S4PLife Time30K(Min.) (Hours)
    Lamp Electrical :Voltage Supply57±3.8VCurrent Supply130/135mA (Typ./Max.)
    Consumption59.3/63.2W (Typ./Max.)
    Interface Features :PositionTypeConnector
    Interface Detail :BrandModelQuantityPinsPitchPin Configuration
    YEONHO20037WR-H121 pcs12 pins2.0 mmBLE-12PINS-CCAACCCCAACC
    Backlight Driver :No

      LG Display LM315QU1-SSA2 Packing Details

      Package Box :QuantityWeightBox Size
      14 pcs / box--

      FAQ:
      Q1: What's the quality of your LCD Panel?
      A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
      Q2: What is your return and refund policy?
      A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
      Q3: How long is the lead time?
      A: The lead time is about 1-3 working days after receipt of payment.
      Q4: How can I get the quotation?
      A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.


      LM315QU1-SSA2 32.0" 7680x4320 Industrial TFT Display 400 cd/m² 89/89/89/89 (Typ.)(CR≥10)
