3840x2160 500cd/m2 Industrial Lcd Panel LG Display 90PPI LC490EGH-FKM1

Ask Lasest Price
Brand Name :	LG Display
Model Number :	LC490EGH-FKM1
Certification :	ISO9001
Payment Terms :	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :	200PCS
Delivery Time :	1-2 DAYS

Add to Cart

Product Details
Company Profile

3840x2160 500cd/m2 Industrial Lcd Panel LG Display 90PPI LC490EGH-FKM1

LG Display LC490EGH-FKM1 Application Details

Basic Detail :	Manufacturer		Model Name	LC490EGH-FKM1
	Panel Type	a-Si TFT-LCD , LCM	Another Name	LC490EGH (FK)(M1)
	Panel Size	49 inch	Designed For
Maximum Ratings :	OP Temperature	0 ~ 50 °C	ST Temperature	-20 ~ 60 °C

LG Display LC490EGH-FKM1 Optical Details

Basic Information :	Luminance	500 cd/m² (Typ.)	Contrast Ratio	1400 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	8/10 (Typ.)(Tr/Td) (ms)
	Viewing Angle	89/89/89/89 (Min.)(CR≥10)	Operating Mode	IPS, Normally Black, Transmissive
Color Performance :	Chromaticity	Wx:0.281; Wy:0.288	Support Color	1.07B (10-bit)
Color Performance :	Color Temperature	9966K	White Uniformity	1.54 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	79%	sRGB	100% coverage
	Adobe RGB	77% coverage	DCI-P3	82% coverage
	Rec.2020	59% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LC490EGH-FKM1 Mechanical Details

Pixel Features :	Number of Pixel	3840(3)×2160 [UHD]	Arrangement	RGBW Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.09321×0.27963 mm	Pixel Pitch(W×H)	0.27963×0.27963 mm [90PPI]
Physical Size :	Active Viewing	1073.78(W)×604(H) mm	Overall Dim.	1095.6(W)×633.4(H) mm
Physical Size :	Bezel Opening	1079.8(W)×609.3(H) mm	Overall Depth	15.5 (Typ.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio(W:H)	16:9	Shape Style
Other Detail :	Mass	9.00/9.50Kgs (Typ./Max.)	Surface	Antiglare (Haze 3%), Hard coating (2H)

LG Display LC490EGH-FKM1 Interface Details

Signal Electrical :	Input Current	1.09/1.42A (Typ./Max.)		Input Voltage	12.0V (Typ.)
Signal Electrical :	Consumption	13.8/18.0W (Typ./Max.)	Signal Interface	EPI
Interface Features :	Position		Physical Type	Connector
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :	HRS	TF06L-60S-0.5SH	2 pcs	0.5 mm	60 pins

LG Display LC490EGH-FKM1 Lightting Details

Lamp Features:	Lamp Shape	-	Lamp Type	WLED	Position	Edge light type (Bottom side)
Lamp Features:	Exchange	-	Amount	-	Life	30K(Typ.) (Hours)
Lamp Electrical :	Input Current	109.3/115/120.8mA (Min./Typ./Max.)		Input Voltage	107.2/111.0/118.8V (Min./Typ./Max.)
Lamp Electrical :	Consumption	76.6/82W (Typ./Max.)
Interface Features :	Position	-	Physical Type	Connector
Interface Detail :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
	UJU	HS100-L08N-N62	1 pcs	1.0 mm	8 pins	BLE-8PINS-CCCNNNNA
	UJU	HS100-L08N-N62-A	1 pcs	1.0 mm	8 pins	BLE-8PINS-ANNNNCCC
Backlight Driver :	No

LG Display LC490EGH-FKM1 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	20 pcs / box	1300×1140×825 mm	-

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
