    LP156WU1-SPB1 LG Display 15.6" 1920(RGB)×1200, WUXGA 144PPI 500 cd/m² INDUSTRIAL LCD DISPLAY

    Ask Lasest Price
    Brand Name : LG DISPLAY
    Model Number : LP156WU1-SPB1
    Certification : ISO9001
    Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION
    Supply Ability : 800PCS
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    LP156WU1-SPB1 LG Display 15.6" 1920(RGB)×1200, WUXGA 144PPI 500 cd/m² INDUSTRIAL LCD DISPLAY

    LG Display LP156WU1-SPB1 Mechanical Features

    Panel Size :15.6 inch
    Pixel Features :ResolutionPixel ArrangementDot Pitch (W×H)Pixel Pitch (W×H)
    1920(RGB)×1200, WUXGARGB Vertical Stripe0.0584×0.1752 mm0.1752×0.1752 mm [144PPI]
    Mechanical Size :Active Area (W×H)Bezel Area (W×H)Outline Dimension (W×H)Outline Depth
    336.38×210.24 mm-340.26×218.02 mm2.3/4.26 (Typ./Max.) mm
    Outline Features :Form StyleAspect RatioOrientationShape Style
    Flat Rectangle16:10 (W : H)Landscape typeSlim (PCBA Bent, T≤3.0mm)
    Fixation :Without
    Other Features :Panel CoverWeightSurface
    -324g (Max.)Antiglare, Hard coating (3H)

    LG Display LP156WU1-SPB1 Optical Features

    Basic Information :BrightnessOperating ModeContrast Ratio
    500 cd/m² (Typ.)ISP, Normally Black, Transmissive1650:1 (Typ.) (Transmissive)
    Viewing Angle(L/R/U/D)Viewing DirectionResponse Speed
    89/89/89/89 (Min.)(CR≥10)Symmetry25 (Typ.)(Tr+Td) (ms)
    Dispaly Color :Color TemperatureColor AmountWhite color Chromaticity
    6485K16.7M (8-bit)X:0.313; Y:0.329
    1931 Color Gamut :NTSC RatiosRGB CoverageAdobe RGB Coverage
    80%100%82%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    84%60%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    Luminance Variation :1.25/1.54 (Max.)(5/13 points)

    LG Display LP156WU1-SPB1 Interface Features

    Signal Electrical :Current InputVoltage InputConsumption
    115/127mA (Typ./Max.)3.3V (Typ.)0.38/0.42W (Typ./Max.)
    Interface Features :PositionTypeInterface
    ConnectoreDP (2 Lanes), eDP1.4b, HBR2 (5.4G/lane)
    Signal Interface :BrandModelAmountPin PitchPinsPin Assignment
    I-PEX20682-040E-021 pcs0.4 mm40 pins

    LG Display LP156WU1-SPB1 Backlight Features

    Backlight Features:TypePositionShapeAmountLife(Hours)Replacement
    WLEDEdge light type--15K(Min.)-
    Interface Features :PositionTypeWLED Driver
    -Included in signal interfaceWith LED Driver
    Driver Electrical :Current InputVoltage InputConsumption
    271/284mA (Typ./Max.)5.0/12.0/20.0V (Min./Typ./Max.)3.25/3.41W (Typ./Max.)

    LG Display LP156WU1-SPB1 Packing Features

    Package TypePcs/PackageBox/PackagePackage LWH (mm)G.W (kgs)Volume (m³)Remarks
    Carton281427×327×328N/A0.0458
    Pallet50418N/AN/AN/A

    LP156WU1-SPB1 LG Display 15.6" 1920(RGB)×1200, WUXGA 144PPI 500 cd/m² INDUSTRIAL LCD DISPLAYFAQ:

    Q1: What's the quality of your LCD Panel?
    A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
    Q2: What is your return and refund policy?
    A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
    Q3: How long is the lead time?
    A: The lead time is about 1-3 working days after receipt of payment.
    Q4: How can I get the quotation?
    A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
